| Exemplar |
DOP-107CV |
DOP-107EV |
| Propono Panel genus |
7″ TFT LCD (65535 colores) |
| Resolution |
800 x 480 elementa |
| Backlight |
DUXERIT Lux (media vita sub cella temperies 25°C> 20000 horas) *1 |
| Propono range |
154.08 x 85.92 mm |
| splendor |
400 cd / m² (Typ.) |
| CPU |
ARM Cortex-A8 (800 MHz) |
| Flash ROM |
256 Mbytes |
| RAM |
256 Mbytes |
| Touchscreen |
IV-filum resistentia touchscreen> 10,000,000 operated |
| Buzzer |
Multi-tonus Frequentia (2K – 4K Hz) / 80 dB |
| Network interface |
N/A |
1 Portus, 10 / 100 Mbps auto deprehensio (in ambitu separatim constructo) * 2 |
| USB |
1 USB Slavus Ver. 2.0; 1 USB Host Ver. 2.0 |
| SD |
N/A |
| Vide communicationis portum
COM1 |
RS-232 (subsidium fluxus control) *2 |
| COM2 |
RS-232 (confluentia subsidii moderaminis) / RS-485*2 |
| COM3 |
RS-422/ RS-485*2 |
| Munus auxiliaris clavis |
N/A |
| Calendarium |
inaedificata |
| Modus refrigerandi |
Natural refrigeratio |
| Approbationes |
CE / UL (placere utere retis tegendis funem et anulum magneticum cum colum 300 ohm / 100 MHz) |
| Panel IMPERVIUS level |
IP65/NEMA4/UL TYPE 4X (tantum umbraticis usus) |
| Operatio voltage* 2 |
DC +24V (-15% ad XV%) (placere uti copia solitaria potentia)
Supple a Classis II vel SELV ambitu (solatus a MAINS per duplex velit) |
| Lacus current |
500 VAC pro 1 minuto (inter DC24V terminatio et FG terminatio) |
| Virtus consummatio *2 |
8.5 W (Max) *3 |
8.76 W (Max) *3 |
| Tergum altilium |
3V Lithium altilium CR2032 1 |
| Tergum autonomía |
De III annis vel ad XXV ° C *
(Re ad operationem temperatus et conditio) |
| Operatio temperatus |
0°C ad 50°C (32°F ad 122°F) |
| Repono temperatus |
-20°C ad +60°C (-4°F ad 140°F) |
| Operans environment |
10% ad 90% RH [0°C – 40°C], 10% ad 55% RH [41°C – 50°C];
pollutio gradus: 2 |
| Repugnantia vibratio |
Conformat IEC61131-2: vibratio continua 5 Hz – 8.3 Hz cum amplitudine 3.5 mm; 8.3 Hz – 150 Hz cum amplitudine 1G |
| Repugnantia inpulsa |
Conformat IEC60068-2-27;
11 ms, 15 G Peak, in X, Y, Z directiones singulas pro 6 vicibus |
| Dimension
(W) x (H) x (D) mm* |
215 x 161 x 61.2 |
| Adscendens dimensio
(W) x (H) mm* |
196.9 x 142.9 |
| Pondus |
Proxime. 970 g |
