| Renault Module |
FX3G/FX3GC/FX3GE |
FX3U/FX3UC |
Auxiliares mensae |
7,680 total, 384 generalibus (M0 – M383), 1,152 EEPROM insertis (M384 – M1535).
et 6,144 general/libitum palatum (M1536 – M7679) |
7,680 total, cum 500 generalibus (M0 – M499), 524 ad libitum insertum (M500 – M1023), et 6,656 insertum (M1024 – M7679) |
publicas mensas |
4,096 totalis, 1,000 EEPROM palatum (S0 - S999)
et 3,096 general/libitum palatum (S1000 - S4095) |
4,096 total, cum 1,000 ad libitum palatum (S0 - S999)
and 3,096 palatum (S1000 - S4095) |
Timers |
320 summa, with
206 100 ms (T0 – T199 et T250 – T255). 46 10 ms (T200 – T245); et 68 1 ms (T246 - T249 et T256 - T319) |
512 totum, with
206 100 ms (T0 - T191, T192 - T199 et T250 - T255); 46 10 ms (T200 – T245); et 260 1 ms (T246 - T249 et T256 - T511) |
Calculis |
235 totum (16 bis et 32 bis);
with 36 general (C0 - C15 et C200 - C219) et 199 EEPROM palatum (C16 – C199 et C220 – C234). |
235 totum (16 bis et 32 bis);
cum CXX generalibus (C0 - C99 et C200 - C219) et 115 palatum (C100 – C199 et C220 – C234). |
Summus celeritate contra celeritatem |
1-phase, 6 puncta max: 60 kHz / 4 puncta;
10 kHz / 2 puncta 2-phase, 3 puncta max: puncta 30 kHz/2; 5 kHz/1 punctum |
1-phase, 8 puncta max: 100 kHz / 6 puncta
10 kHz / 2 puncta 2-phase, 2 puncta max: 50 kHz / 2 puncta |
Data registra |
8000 total, cum 128 generalibus (D0 – D127), 972 EEPROM insertis (D128 – D1099);
et 6,900 generalis/ ad libitum palatum (D1100 - D7999) |
8,000 total, cum 200 generalibus (D0 – D199), 312 ad libitum insertum (D200 – D511);
et 7,488 palatum (D512 – D7999) |
| Extensio registra |
24,000(R0 - R23999) |
32,768(R0 - R32767) |
| Extensio fasciculi registri |
24,000(ER0 - R23999) internus/libitum memoriae |
32.768(ER0 - R32767) memoria ad libitum |
