| Item |
Q02PHCPU |
Q06PHCPU |
Q12PHCPU |
Q25PHCPU |
| Imperium modum |
Progressio cyclica operatio condita |
| I / O imperium modus |
Renovare |
| Sequentia in lingua latina |
• Nullam figuram linguae (scala) • Logica lingua symbolica (list) • MELSAP3 (SFC), MELSAP-L
• Function obstructionum • Structured text (ST) |
| Processus controlling |
• processus imperium FBD * 1 |
| Peripheralconnection portum USB |
|
| Peripheralconnection portum RS-232 |
|
| Memoria card interface |
(SRAM card, Flash card, ATA card) |
| LD disciplinam |
34 ns |
| MOV disciplinam |
102 ns |
| PC MIX value (instruction/μs)*3 |
10.3 |
| fluctuetur additione |
0.78 µs |
| Totalis numerus instructiones * IV ' |
757 |
| fluctuetur disciplinam |
|
| Mores filum processus disciplinam |
|
| PID disciplinam |
- |
| Processus imperium disciplinam |
|
| Munus speciale instructio (munus trigonometricum, radix quadrata, operatio exponentialis, etc.) |
|
| Constant scan (Function for observatio temporis scan regularis) |
0.5…2000 ms (propositiones praesto per turmas 0.5 ms) |
| Facultas Program |
28K gradus |
60K gradus |
124K gradus |
252K gradus |
| Numerus I/O puncta fabrica [X/Y] |
8192 puncta |
| Numerus puncta I/O [X/Y] |
4096 puncta |
| Nullam [M]*5 |
8192 puncta |
| Claustrum Nullam [L]*5 |
8192 puncta |
| Vinculum vita [B]*5 |
8192 puncta |
| Timer [T]*5 |
MMXLVIII puncta |
| Retentive timer [ST]*5 |
0 punctum |
| [C]*5 |
1024 puncta |
| Data mandare [D]*5 |
12288 puncta |
| Link register [W]*5 |
8192 puncta |
| Annunciator [F]*5 |
MMXLVIII puncta |
| Ora Nullam [V]*5 |
MMXLVIII puncta |
| Link speciale Nullam [SB] |
MMXLVIII puncta |
| Link special mandare [SW] |
MMXLVIII puncta |
| Tabularii tabularii [R, ZR] |
65536 puncta 6 |
131072 puncta 6 |
| Nullam Gradus [S]; |
8192 puncta |
| Index registri [Z] |
16 puncta |
| Regula [P] |
4096 puncta |
| Interpellare monstratorem [I] |
256 puncta |
| Nullam specialem [SM] |
MMXLVIII puncta |
| Mandatum speciale [SD] |
MMXLVIII puncta |
| Munus initus [FX] |
16 puncta |
| Munus output [FY] |
16 puncta |
| Munus registri [FD] |
5 puncta |
| Locus fabrica |
|
| Device initial values |
|
