| Supple intentione Vs |
DC 12 V ... 30 V 1) 2) |
| Ripple |
≤ 5 Vpp 3) |
| Virtus consummatio |
≤ 1.7 W 4) 5) |
| Initialization tempore |
≤ 500 ms |
| Fermentum tempus |
≤ 20 min |
| Praesent materia |
Plastic (ABS/PC) |
| Fenestra materia |
Plastic (PMMA) |
| Genus nexu |
Masculinum iungo M12, 5-pin |
| Indicium |
LEDs |
| Pondus |
65 g |
| Dimensiones (W x H x D) |
32 mm x 58.67 mm x 42.7 mm |
| Clausura rating |
IP65
IP67 |
| Praesidium classis |
III |
| range mensuræ |
50 mm ... 12,000 mm, 90% remissio 1) 2)
50 mm ... 5,300 mm, remissio 18% 50 mm ... 3,100 mm, 6% remissio |
| Target |
Naturalia |
| Resolution |
0.1 mm |
| Repeatability |
≥ 0.5 mm 2) 3) 4). |
| Sagacitas |
Typ. ± 10 mm 4) |
| Responsum tempus |
2.5 ms ... 96.5 ms, 2.5 ms / 6.5 ms / 12.5 ms / 24.5 ms / 96.5 ms 5) 6) |
| Commutatione frequency |
333 Hz / 100 Hz / 50 Hz / 25 Hz / 6 Hz 5) 6) |
| Output tempore |
1 ms ... 32 ms, 1 ms/2 ms/4 ms/8 ms/32 ms 5) 7) |
| Lux fons |
Laser, infrared 8)
visibilis lux rubra |
| Laser classis |
1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Typ. luce macula magnitudine (distantiam) |
15 mm x 15 mm. |
| Additional munus |
Pone velocitatem: Eximius Fast ... Eximius tardus, doce-in analogum output et invertibilem analogum output, output Q2 aptum: Current output / intentione output / Digital output, Switching modum: Distantia obiecti (DtO) / switching fenestra / obiectum inter sensorem et background (ObSB), doce-in of digital output et digital output invertibile, Multifunctional input / defecerat officinas ad objectum (DtO) / switching fenestra / obiectum inter sensorem et background (ObSB), doce-in of digital output et digital output invertibile, multifunctional input / defaltam officinam ad objectum (DtO) / commutatione fenestra / obiectum inter sensorem et background (ObSB), doce-in of digital output et digital output invertibile, multifunctional input / defectionis officinas ad obiecti |
