| Model NPN output | GT2-100N | GT2-E3N |
| PNP output | GT2-100P | GT2-E3P |
| Mounting type | Panel mount | – |
|
Number of connectable heads | 2 heads with GT2-100N(P) alone
+ 3 heads per 1 head board expansion When expanded with a maximum of 3 head boards, 11 heads |
– |
| Power supply voltage | 10 to 30 VDC, including 10% ripple (P-P), Class 2 | Supplied from the GT2-100N/100P |
| Display range | -199.999.9 to 199.999.9 | – |
| Display resolution | 0.1 μm | – |
| Normal | 4500 mW or less (150.0 mA or less at 30 V) | 4200 mW or less (140.0 mA or less at 30 V) |
| Power saving (Eco half) *1 | 3700 mW or less (123.3 mA or less at 30 V) | 4200 mW or less (140.0 mA or less at 30 V) |
| Power saving (Eco all)*1 | 3600 mW or less (120.0 mA or less at 30 V) | 4000 mW or less (133.3 mA or less at 30 V) |
| Response time | hsp (3)/5/10/100/500/1000 ms
(When using GT2-Pxxx, hsp (12)/20/40/400/2000/4000 ms) |
| Input/output connector *2 | Power supply: Terminal block connection Input/output: 20-pin connector (MIL standard) | 30-pin connector (MIL standard) |
| Ambient temperature | -10 to +50°C 14 to 122°F (No freezing) |
| Relative humidity | 35 to 85% RH (No condensation) |
| Vibration | 10 to 55 Hz Double amplitude 0.15 mm 0.01″ in the X, Y, Z axis directions respectively, 2 hours |
|
Materials | Main body case/front cover: polycarbonate (PC), Key top: polyacetal (POM),
Front sheet: polyethylene terephthalate (PET) |
– |
| Weight | Approx. 380 g | Approx. 80 g |
