| Article number | 6GK5875-0AA10-1AA2 |
| Product type designation | SCALANCE M875 UMTS ROUTER |
| Transmission rate |
|
| Transfer rate | 10 Mbit/s, 100 Mbit/s |
| Transfer rate |
|
|
● for GSM transmission | 9 600 bit/s |
|
● for GPRS transmission with downlink maximum | 85.6 kbit/s |
|
● for GPRS transmission with uplink maximum | 42.8 kbit/s |
|
● with eGPRS transmission with downlink maximum | 236.8 kbit/s |
|
● with eGPRS transmission with uplink maximum | 118 kbit/s |
|
● with UMTS transmission with downlink maximum | 14.4 Mbit/s |
|
● with UMTS transmission with uplink maximum | 5.76 Mbit/s |
| Interfaces |
|
| Number of electrical connections |
|
|
● for internal network | 2 |
|
● for external network | 2 |
| Number of electrical connections |
|
|
● for power supply | 1 |
| Type of electrical connection |
|
|
● for internal network | RJ45 port (10/100 Mbit/s, TP, autocrossover) |
|
● for external network | SMA antenna socket (50 ohms) |
|
● for power supply | Terminal strip |
| WAN connection |
|
| Type of mobile network is supported | GSM, UMTS |
| Type of mobile wireless service is supported | GPRS, eGPRS, HSPA+ |
| Operating frequency for GSM transmission | 850 MHz, 900 MHz, 1800 MHz, 1900 MHz |
| Operating frequency with UMTS transmission | 800 MHz, 850 MHz, 900 MHz, 1900 MHz, 2100 MHz |
| Supply voltage, current consumption, power loss |
|
| Supply voltage Rated value | 24 V |
| Supply voltage rated value | 12 … 30 |
| Type of voltage of the supply voltage | DC |
| Consumed current at rated supply voltage maximum | 450 mA |
| Power loss [W] |
|
|
● typical | 4 W |
| Permitted ambient conditions |
|
| Ambient temperature |
|
|
● during operation | -40 … +75 °C |
|
● during storage | -40 … +85 °C |
| Relative humidity at 25 °C during operation maximum | 95 % |
| Protection class IP | IP20 |
| Design, dimensions and weight |
|
| Design | compact |
| Depth | 114 mm |
| Width | 45 mm |
| Net weight | 280 g |
| Mounting type |
|
|
● 35 mm DIN rail mounting | Yes |
|
● S7-300 rail mounting | No |
|
● S7-1500 rail mounting | No |
|
● wall mounting | No |
| Product properties, functions, components general |
|
| Product function |
|
|
● DynDNS-Client | Yes |
| Product functions management, configuration |
|
| Product function |
|
|
● CLI | No |
|
● web-based management | Yes |
|
● MIB support | No |
|
● TRAPs via email | No |
| Protocol is supported |
|
|
● Telnet | No |
|
● HTTP | No |
|
● HTTPS | Yes |
| Type of configuration | Web-based management |
| Product functions Diagnosis |
|
| Product function |
|
|
● Statistics Packet Size | No |
|
● Statistics packet type | No |
|
● Error statistics | No |
|
● SysLog | Yes |
|
● Packet Filter Log | Yes |
| Product functions DHCP |
|
| Product function |
|
|
● DHCP client | Yes |
|
● DHCP server – internal network | Yes |
| Product functions Routing |
|
| Router function |
|
|
● NAT (IP masquerading) | Yes |
|
● Port forwarding | Yes |
|
● NAT traversal | Yes |
|
● 1:1 NAT | Yes |
|
● DNS cache | Yes |
| Product functions Security |
|
| Suitability for operation Virtual Private Network | Yes |
| Firewall version | Statefull Inspection |
| Product function |
|
|
● Password protection | Yes |
|
● packet filter | Yes |
|
● Broadcast/Multicast/Unicast Limiter | No |
| Product function |
|
|
● broadcast blocking | No |
|
● with VPN connection | IPSec |
| Number of possible connections with VPN connection | 10 |
| Type of authentication with Virtual Private Network PSK | Yes |
| Protocol is supported |
|
|
● IPsec tunnel and transport mode | Yes |
| Key length |
|
|
● with IPsec DES with Virtual Private Network | 56 bit |
|
● 1 with IPsec AES with Virtual Private Network | 128 bit |
|
● 2 with IPsec AES with Virtual Private Network | 192 bit |
|
● 3 with IPsec AES with Virtual Private Network | 256 bit |
|
● with IPsec 3DES with Virtual Private Network | 168 bit |
| Type of Internet key exchange with Virtual Private Network |
|
|
● main mode | Yes |
|
● quick mode | Yes |
| Type of packet authentication with Virtual Private Network | MD5, SHA-1 |
| IETF profile with Virtual Private Network X.509v3 certificate | Yes |
| Product functions Time |
|
| Protocol is supported |
|
|
● NTP | Yes |
| Standards, specifications, approvals |
|
| Standard |
|
|
● for safety from CSA and UL | yes |
|
● for emitted interference | EN55022 Class A |
|
● for interference immunity | EN 61000-6-2 |
| Certificate of suitability | EN 61000-6-2 |
|
● CE marking | Yes |
|
● E1 approval | No |
|
● E1 approval | No |
|
● Railway application in accordance with EN 50121-3-2 | Yes |
|
● Railway application in accordance with EN 50155 | Yes; no coated printed circuit boards |
|
● railway application in accordance with EN 61373 | Yes; cat. 1, cl. B |
