Siemens SQN71.424B20 SQN71 Series Burner Damper Actuator, 2.5Nm, 12s/90°, Clockwise

Series#: Damper Actuator -> Siemens -> SQN Series
- Siemens SQN71.424B20 Burner Damper Actuator, 2.5Nm, 12s/90°, Clockwise
- We have large inventory for Siemens SQN series burner actuators and combustion controls.
- 100% Original and new, In stock by Eaton Company.
- Delivery time: Ready in stock and 1 days for ship out
- MOQ: 1pcs

Availability:



Inquire

Model:
SQN71.424B20
Brand:
Siemens

Product Description

The Siemens SQN71.424B20 is a clockwise-rotation variant of the SQN7 series burner damper actuator, delivering 2.5 Nm torque with 12-second running time for 90° rotation. It uses a synchronous motor at ~6 VA with up to 160° angular range and 1.2 Nm holding torque. Unlike the SQN72 (counterclockwise), the SQN71 rotates clockwise, making it suitable for specific burner configurations. Applications include industrial combustion air damper control, fuel valve modulation, and process heating systems where clockwise actuation is required.

**Q: What is the difference between SQN71 and SQN72?**
A: SQN71 rotates clockwise; SQN72 rotates counterclockwise. The torque and timing specifications are otherwise identical for the same variant suffix (.4 = 12s, 2.5 Nm).

Technical Specifications

Siemens SQN71.424B20
Damper Actuator -> Siemens -> SQN Series \| Siemens SQN71.424B20 SQN71 Series Burner Damper Actuator, 2.5Nm, 12s/90°, Clockwise
Feature	Specification
Feature	Specification
Product Series	SQN71
Product Type	Damper Actuator / Servomotor
Nominal Torque	2.5 Nm
Holding Torque	1.2 Nm
Running Time (90° at 50 Hz)	12 seconds
Angular Positioning Range	Max. 160°
Rotation Direction	Clockwise
Motor Type	Synchronous motor
Power Consumption	~6 VA
Designed Lifetime	250,000 start cycles
Degree of Protection	IP40 or IP54
Weight	~500–800 g
Application	Oil/gas burner air damper and fuel valve control
Shaft Load Radial (max)	100 N
Shaft Load Axial (max)	10 N
Limit Switches	2
Auxiliary Switches	2
Position Feedback	Yes (analog output)
Supply Voltage	230V AC 50/60 Hz
Protection Degree	IP40 (IP54 on request)
