TRICO TXL 025-24S DIN-Rail Power Supply

Power Supplies - Chassis Mount 25W AC/DC Power Supply in a Chassis Mount Metal Case
Availability:
Inquire

  • TXL 025-24S

  • TRICO

Product Description

Series#: Power Supply->TRICO Power Supply

Download A Munual

Attribute
Value
Output Voltage
24 VDC
Output Adjustment 1
21.6-26.4 VDC
Output Current
1100 mA
Power Rating
25 W
Number of Outputs
single
Input Voltage
88-264 VAC / 125-375 VDC
Housing Type
Metal Case
Mounting Type
Chassis Mount
Connection Type
Screw Terminal
Length
79 mm
Width
28.5 mm
Depth
51 mm
Efficiency
86 %
Maximum Temperature
70 °C
Minimum Temperature
-10 °C
Weight
180 g
Ripple and Noise
150 mVp-p max.
Remote On/Off
No
Safety Approvals
EN 60950-1, EN 62368-1
Insulation System
Reinforced Insulation
I/O Isolation Voltage
3000 VAC


Relevant documents
download txl025_datasheet.pdf
