| Rhif yr erthygl |
6ES7223-1BH32-0XB0 |
6ES7223-1BL32-0XB0 |
6ES7223-1BL32-1XB0 |
6ES7223-1PH32-0XB0 |
6ES7223-1PL32-0XB0 |
6ES7223-1QH32-0XB0 |
|
Digidol I/O SM 1223, 8 DI / 8 DO |
I/O digidol SM 1223, 16DI/16DO |
Sinc digidol I/O SM 1223, 16DI/16DO |
I/O digidol SM 1223, 8DI/8DO |
I/O digidol SM 1223, 16DI/16DO |
Digidol I/O SM 1223, 8DI AC/ 8DO Rly |
| Gwybodaeth gyffredinol |
|
|
|
|
|
|
| Dynodiad math o gynnyrch |
SM 1223, DI 8×24 V DC, DQ 8×24 V DC |
SM 1223, DI 16×24 V DC, DQ 16×24 V DC |
SM 1223, DI 16×24 V DC, DO 16x 24 V DC Sink |
SM 1223, DI 8 × 24 V DC, ras gyfnewid DQ 8x |
SM 1223, DI 16 × 24 V DC, ras gyfnewid DQ 16x |
SM 1223, DI 8×120/230 V AC, ras gyfnewid DQ 8x |
| Foltedd cyflenwad |
|
|
|
|
|
|
| Gwerth graddedig (DC) |
24 V |
24 V |
24 V |
24 V |
24 V |
24 V |
| ystod a ganiateir, terfyn isaf (DC) |
20.4 V |
20.4 V |
20.4 V |
20.4 V |
20.4 V |
20.4 V |
| ystod a ganiateir, terfyn uchaf (DC) |
28.8 V |
28.8 V |
28.8 V |
28.8 V |
28.8 V |
28.8 V |
| Cerrynt mewnbwn |
|
|
|
|
|
|
| o backplane bws 5 V DC, max. |
145 mA |
185 mA |
185 mA |
145 mA |
180 mA |
120 mA |
| Mewnbynnau digidol |
|
|
|
|
|
|
| · ● o foltedd llwyth L+ (heb lwyth), uchafswm.
· |
4 mA; fesul sianel |
4 mA; fesul sianel |
4 mA; fesul sianel |
4 mA/mewnbwn 11 mA/cyfnewid |
4 mA/mewnbwn 11 mA/cyfnewid |
|
| Foltedd allbwn |
|
|
|
|
|
|
| Cyflenwad pŵer i'r trosglwyddyddion |
|
|
|
|
|
|
| ·● yn bresennol
· |
Oes |
Oes |
Oes |
Oes |
Oes |
Oes |
| Colli pŵer |
|
|
|
|
|
|
| Colli pŵer, typ. |
2.5 C |
4.5 Gw |
4.5 Gw |
5.5 Gw |
10 gw |
7.5 C |
| Mewnbynnau digidol |
|
|
|
|
|
|
| Nifer y mewnbynnau digidol |
8 |
16 |
16 |
8 |
16 |
8 |
| ·● mewn grwpiau o
· |
2 |
2 |
2 |
2 |
2 |
4 |
| Mewnbwn cromlin nodweddiadol yn unol ag IEC 61131, math 1 |
Oes |
Oes |
Oes |
Oes |
Oes |
Oes |
| Nifer y mewnbynnau y gellir eu rheoli ar yr un pryd |
|
|
|
|
|
|
| pob safle mowntio |
|
|
|
|
|
|
| ·— hyd at 40 ° C, uchafswm.
· |
8 |
16 |
16 |
8 |
16 |
8 |
| gosodiad llorweddol |
|
|
|
|
|
|
| ·— hyd at 40 ° C, uchafswm.
· |
8 |
16 |
16 |
8 |
16 |
8 |
| ·— hyd at 50 ° C, uchafswm.
· |
8 |
16 |
16 |
8 |
16 |
8 |
| gosodiad fertigol |
|
|
|
|
|
|
| ·— hyd at 40 ° C, uchafswm.
· |
8 |
16 |
16 |
8 |
16 |
8 |
| Foltedd mewnbwn |
|
|
|
|
|
|
| · ● Math o foltedd mewnbwn
· |
DC |
DC |
DC |
DC |
DC |
AC |
| ·● Gwerth graddedig (DC)
· |
24 V |
24 V |
24 V |
24 V |
24 V |
|
| ·● Gwerth graddedig (AC)
· |
|
|
|
|
|
120/230 V AC |
| ·● ar gyfer signal '0'
· |
5 V DC ar 1 mA |
5 V DC ar 1 mA |
5 V DC ar 1 mA |
5 V DC ar 1 mA |
5 V DC ar 1 mA |
20 V AC ar 1 mA |
| ·● ar gyfer signal '1'
· |
15 V DC ar 2.5 mA |
15 V DC ar 2.5 mA |
15 V DC ar 2.5 mA |
15 V DC ar 2.5 mA |
15 V DC ar 2.5 mA |
79 V AC ar 2.5 mA |
| Cerrynt mewnbwn |
|
|
|
|
|
|
| ·● ar gyfer signal '0', uchafswm. (cerrynt tawel a ganiateir)
· |
1 mA |
1 mA |
1 mA |
1 mA |
1 mA |
1 mA |
| ·● ar gyfer signal '1', mun.
· |
2.5 mA |
2.5 mA |
2.5 mA |
2.5 mA |
2.5 mA |
2.5 mA |
| ·● ar gyfer signal '1', teipiwch.
· |
4 mA |
4 mA |
4 mA |
4 mA |
4 mA |
9 mA |
| Oedi mewnbwn (ar gyfer gwerth graddedig y foltedd mewnbwn) |
|
|
|
|
|
|
| ar gyfer mewnbynnau safonol |
|
|
|
|
|
|
| ·— paramedradwy
· |
Oes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms a 12.8 ms, yn ddetholadwy mewn grwpiau o bedwar |
Oes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms a 12.8 ms, yn ddetholadwy mewn grwpiau o bedwar |
Oes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms a 12.8 ms, yn ddetholadwy mewn grwpiau o bedwar |
Oes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms a 12.8 ms, yn ddetholadwy mewn grwpiau o bedwar |
Oes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms a 12.8 ms, yn ddetholadwy mewn grwpiau o bedwar |
Oes; 0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms a 12.8 ms, yn ddetholadwy mewn grwpiau o bedwar |
| Pwysau |
|
|
|
|
|
|
| Pwysau, tua. |
210 g |
310 g |
310 g |
230 g |
350 g |
230 g |
