| Type |
Standard |
Exemplar pro
Sensor Communications
Unit *1 |
|
|
| NPN output |
E3X-HD11 |
E3X-HD6 |
E3X-HD14 |
E3X-HD0 |
| PNP output |
E3X-HD41 |
E3X-HD8 |
E3X-HD44 |
|
| Modus connectens |
Pre-wired |
Wire-salvis
Connector
*2 |
M8
connector |
Communications
Unit connector |
| Lux fons (necem) |
Red, elementum DUXERIT (um 625) |
|
|
|
| Potentia copia voltage |
12 ad 24 VDC ± 10%, laniatus (PP) 10% max. |
Supple a iungente
per Communicationis Sensorem
Unit |
|
|
| Normalis modus |
720 mW max.
(Consumptio current: 30 mA max. ad 24 VDC, 60 mA max. ad 12 VDC) |
|
|
|
| Eco ON |
530 mW max.
(Consumptio current: 22 mA max. ad 24 VDC, 44 mA max. ad 12 VDC) |
|
|
|
| Eco LO |
640 mW max. (Consumptio current: 26 mA max. ad
24 VDC, 53 mA max.at 12 VDC) |
- |
|
|
| Imperium output |
Load power supply voltage: 26.4 VDC max., open-
collector output
Load current:
Groups of 1 to 3 Amplifier Units: 100mA max.,
sodalitates 4 ad 16 Amplifier Unitas: 20mA max.
Residua intentione:
In onere currenti minus quam 10 mA: 1 V max.,
in onere currenti 10 ad 100 mA: 2 V max.
PRAE current: 0.1 mA max. |
- |
|
|
| Praesidium circuitus |
Potestas suppleat verticitatem vicissim praesidio, output
breve spatium tutelae et output contra
verticitatem tutelam |
Potestas supplet verticitatem contra verticitatem
tutelam et output brevis
circuitus tutelae |
|
|
Eximius summus celeritas
modus (SHS) *3 |
NPN outputs: Operate vel reset: 50 μs
PNP outputs: Operate vel reset: 55 μs |
- |
|
|
Princeps celeritate Modus
(HS) |
Agunt vel reset: 250 μs (default occasus) |
|
|
|
Latin Modus
(STND) |
Agunt vel reset: 1 ms |
|
|
|
Modus Giga-potestatis
(GIGA) |
Agunt vel reset: 16 ms |
|
|
|
| Maxime connectable Unitates |
XVI unitates |
cum E3X-CRT: XVI unitates
cum E3X-ECT: XXX unitates |
|
|
Intercessiones mutui
praeventionis |
Possibile est usque ad X unitates (sync communications optical) * III ' |
|
|
|
| Auto imperium imperium (APC) |
Semper ON |
|
|
|
| Alia munera |
Potentia tuning, detectio differentialis, DPC, timer (ON-mora, ON-mora, vel offa),
nulla reset, resetting occasus, modus Eco |
|
|
|
Lumen ambientium
(receptorem parte) |
Lucerna candens: 20000 lx max., lux solis: 30,000 lx max. |
|
|
|
| Ambiens temperatus range |
OOperating:
Circuli 1 ad 2 Amplificatores: -25 ad 55°C,
Circuli 3 ad 10 Amplificatores: -25 ad 50°C,
Circuli 11 ad 16 Amplificatores: -25 ad 45°C
Repono: -30 ad 70°C
(cum nullo vico vel condensatione) |
Operantes:
Circuli 1 ad 2 Amplificatores:
0 ad 55°C,
Circuli 3 ad 10 Amplificatores:
0 ad 50°C,
Circuli 11 ad 16 Amplificatores:
0 ad 45°C,
Circuli 17 ad 30 Amplificatores:
0 ad 40°C
Repono: -30 ad 70°C
(cum nullo vico vel condensatione) |
|
|
| Ambiens humiditas range |
Operans et repono: XXXV% ad LXXXV% (nulla condensatione) |
|
|
|
| Nulla resistentia |
20 MΩ min. (ad 500 VDC) |
|
|
|
| Dielectric viribus |
1,000 VAC ad 50/60 Hz pro 1 minute |
|
|
|
Repugnantia vibratio
(exitium) |
10 ad 55 Hz cum 1.5-mm amplitudine dupla pro
2 horis singulis in X, Y, Z directionibus |
10 ad 150 Hz cum 0,7-mm
amplitudine dupla pro 80 minutis
singulis in X, Y, Z directionibus |
|
|
Resistentia concussa
(exitium) |
500 m/s2 pro 3 singulis partibus in X, Y, Z
; |
150 m/s2 pro 3 singulis partibus in
X, Y, Z; |
|
|
| Gradus praesidium |
IEC (DCV)XXIX IP50
(cum Protective Cover coniuncta) |
- |
|
|
Pondus
(facis status / unitas only) |
Proxime. 105 g/
Approx. 65 g |
Proxime. 60 g/
Approx. 20 g |
Proxime. 70 g/
Approx. 25 g |
Proxime. 65 g/Approx. 25 g |
| Casus |
Polycarbonate (PC) |
Calor repugnans ABS
(connector: PBT) |
|
|
| Cover |
Polycarbonate (PC) |
|
|
|
| Cable |
PVC |
- |
|
|
| Accessories |
Instructio Manuale |
|
|
|
