| Product genus FP0R imperium unitas |
C10
(Nullam solum genus output) |
C14
(Nullam solum genus output) |
C16
(Transistor output genus solum) |
C32
(Transistor output genus solum) |
T32
(Transistor output genus solum) |
F32
(Transistor output genus solum) |
| Programmandi modum / modum Imperium |
Nullam figuram / Cyclic operation |
Imperium unitatis modo (non expansionem) |
X puncta
[Input: 6, no Output: 4] |
XIV puncta
[Input: 8, no Output: 6] |
16 puncta
[Input: 8, Transistor Output: 8] |
32 puncta
[Input: 16, Transistor . Output: 16] |
32 puncta
[Input: 16, Transistor Output: 16] |
Cum expansion 1 Eadem species imperium et dilatatio unitates (Nota) |
Maximilianus. 58 puncta |
Maximilianus. 62 puncta |
Maximilianus. 112 puncta |
Maximilianus. 128 puncta |
Maximilianus. 128 puncta |
Cum expansion II ' Nullam ac transistoris unitates genus miscere (Nota) |
Maximilianus. 106 puncta |
Maximilianus. 110 puncta |
Maximilianus. 112 puncta |
Maximilianus. 128 puncta |
Maximilianus. 128 puncta |
| Programma memoria |
EEPROM (non altilium tergum requiritur) |
| Facultas Program |
16 k gradibus |
32 k gradibus |
| Numerus instructionum
Basic instructions |
110 typi approx. |
Summus gradus instructiones |
210 genera approx. |
| Operatio celeritas
Gradus ad 3,000 |
Praecepta fundamentalia: 0.08 µs min. Timor instructiones: 2.2 µs min. Instructiones altae: 0.32 µs (instructio) min. |
3,001st. ac deinde gradus |
Praecepta fundamentalia: 0.58 µs min. Timor instructiones: 3.66 µs min. High-level instructiones: 1.62 µs (instructio MV) min. |
Operatio memoriae Nullam Nullam internam (R) |
4,096 puncta |
| Timor / Counter (T/C) |
1,024 puncta |
| Memoria area
Data actis mandare (DT) |
12,315 verba |
32.765 words |
Index registri (IX, IY) |
Verba XIV (IO ad ID) |
| Magister imperium Nullam puncta (MCR) |
256 words |
| Numerus pittacorum (JMP et LAQUEUS) |
256 pittacia |
| Puncta differentialis |
Aequivalet progressio facultatem |
| Numerus gradus scalae |
1,000 gradus |
| Numerus subroutines |
500 subroutines |
| Praecipua munera
Princeps celeritate counter |
Single-phase: 6 puncta (50 kHz max. each) 2-phase: 3 canales (15 kHz max. each) (Nota) |
Pulsus output |
Not available |
4 puncta (50 kHz max. singula) 2 canales singuli regi possunt. (Nota) |
PWM output |
Not available |
4 puncta (6 Hz ad 4.8 kHz); |
Pulsus capere initus / interrumpere initus |
Summa VIII puncta (cum celeritate contra) |
Interpellare programma |
Input: 8 programmata (6 programmata C10 tantum) / periodica: 1 programmata / Pulsus compositus: 4 programmata |
Periodical interrupt |
Per turmas suas 0.5 ms: 0.5 ms ad 1.5 sec. / In paginis 10 ms: 10 ms ad 30 sec. |
Constans scan |
Per turmas suas 0.5 ms: 0.5 ms ad 600 ms |
RS-232C port |
Portus unus RS-232C annectitur singulis C10CRS, C10CRM, C14CRS, C14CRM, C16CT, C16CP, C32CT;
C32CP, T32CT, T32CP, F32CT et F32CP genus (3P scandali terminalis) celeritas transmissionis (Baud rate): 2,400 ad 115, 200 bits/sec., spatium transmissionis: 15 m 9.843 ft. Methodus communicationis: duplex semis. |
Operatio memoriae |
Certa area condita in EEPROM |
Tergum totius regionis per FerAM (sine necessitate altilium) |
|
Peripatetici: 16 puncta Nullam Internam: 128 puncta
Data subcriptio: 315 verba |
Tergum totius
spatio aedificatur secunda pugna |
|
Functio auto-diagnostica |
Watchdog timer (690 ms approx.), syntaxin programmatis perscriptio |
| Real-time horologium munus |
Not available |
Praesto |
Not available |
Alia munera |
Rewriting in RUN modus, download in CURSUS modus (incl. comment) 8-character password occasu, et programma onerationis praesidium |
