Articulus numerus |
6ES7331-7RD00-0AB0 |
6ES7331-7SF00-0AB0 |
|
SIMATIC S7, SM 331 ANALOGUS INPUT |
SIMATIC S7, SM 331 ANALOGUS INPUT |
Supple voltage |
|
|
Load voltage L+ |
|
|
Ratum valorem (DC) |
24 V |
24 V |
Reverse verticitatem praesidium |
Ita |
|
Input current |
|
|
from load voltage L+ (sine onere), max. |
250 mA |
|
a backplane bus 5 V DC, max. |
60 mA |
120 mA |
Output voltage |
|
|
Virtus copiam ad transmitters |
|
|
Ratum valorem (DC) |
13 V; at 22 mA |
|
Virtus damnum |
|
|
Virtutis amissio, typ. |
3 W |
0,6 W |
Analog inputs |
|
|
Numerus Analog inputs |
4 |
8; 8x thermocouples; 4x RTD thermoresistors |
licet initus currentis pro currenti input (modum destruendi), max. |
40 mA |
|
Input iugis |
|
|
Voltage |
No |
Ita |
Current |
Ita |
No |
Thermocouple |
No |
Ita |
Resistentia thermometri |
No |
Ita |
Resistentia |
No |
Ita |
Input ranges (valores aestimavit), voltages |
|
|
-1 V ad +1 V |
|
Ita |
- Input resistentia (1 V ad +1 V) |
|
10 MΩ |
-25 mV ad +25 mV |
|
Ita |
— Input resistentia (-25 mV ad +25 mV) |
|
10 MΩ |
-250 mV ad +250 mV |
|
Ita |
— Input resistentia (-250 mV ad +250 mV) |
|
10 MΩ |
-50 mV ad +50 mV |
|
Ita |
— Input resistentiam (-50 mV ad +50 mV) |
|
10 MΩ |
-500 mV ad +500 mV |
|
Ita |
— Input resistentia (-500 mV ad +500 mV) |
|
10 MΩ |
-80 mV ad +80 mV |
|
Ita |
— Input resistentiam (-80 mV ad +80 mV) |
|
10 MΩ |
Input ranges (valores aestimavit), currentes |
|
|
0 ad 20 mA |
Ita |
|
- Input resistentiam (0 ad 20 mA) |
50 Ω |
|
4 mA ad 20 mA |
Ita |
|
— Input resistentia (4 mA ad 20 mA) |
50 Ω |
|
Input septa (valores aestimavit), thermocouples |
|
|
Type B |
|
Ita |
- Repugnantia potenti (Type B) |
|
10 MΩ |
Typus E |
|
Ita |
- Input resistentiam (Type E) |
|
10 MΩ |
Typus J |
|
Ita |
- Repugnantia potenti (type J) |
|
10 MΩ |
Typus K |
|
Ita |
- Input resistentiam (Type K) |
|
10 MΩ |
Type L |
|
Ita |
- Input resistentiam (Type L) |
|
10 MΩ |
Type N |
|
Ita |
- Input resistentia (Type N) |
|
10 MΩ |
Type R |
|
Ita |
- Repugnantia potenti (Type R) |
|
10 MΩ |
Type S |
|
Ita |
- Input resistentiam (Type S) |
|
10 MΩ |
Type T |
|
Ita |
- Input resistentia (Type T) |
|
10 MΩ |
Typus U |
|
Ita |
- Input resistentiam (Type U) |
|
10 MΩ |
