| Mitsubishi MELSERVO-J4 servomotori |
motor |
HG-SR 1000 r/min seriyali
(3 fazali 200 V o'zgaruvchan tok bilan mos keladi, o'rtacha inertsiya / o'rtacha quvvat) |
HG-SR 2000 r/min seriyali (3 fazali 200 V AC bilan mos keladi,
o'rta inertsiya / o'rta sig'im) |
|
|
|
|
|
|
|
|
|
|
|
| Mitsubishi MR-J4 servomotori |
motor |
51(B) |
81(B) |
121
(B) |
201
(B) |
301
(B) |
421
(B) |
52(B) |
102
(B) |
152
(B) |
202
(B) |
352
(B) |
502
(B) |
702
(B) |
| Uzluksiz ishlaydigan vazifa (1-eslatma)
Nominal chiqish |
[kVt] |
0.5 |
0.85 |
1.2 |
2.0 |
3.0 |
4.2 |
0.5 |
1.0 |
1.5 |
2.0 |
3.5 |
5.0 |
7.0 |
|
Nominal moment |
[N•m] |
4.8 |
8.1 |
11.5 |
19.1 |
28.6 |
40.1 |
2.4 |
4.8 |
7.2 |
9.5 |
16.7 |
23.9 |
33.4 |
| Maksimal moment (eslatma 10, 13) |
[N•m] |
14.3 |
24.4 |
34.4 |
57.3 |
85.9 |
120 |
7.2 |
14.3 |
21.5 |
28.6 |
50.1 |
71.6 |
100
(134) |
| Nominal tezlik (1-eslatma) |
[d/daq] |
1000 |
2000 |
|
|
|
|
|
|
|
|
|
|
|
| Maksimal tezlik (eslatma 10) |
[d/daq] |
1500 |
3000 |
|
|
|
|
|
|
|
|
|
|
|
| Bir lahzali ruxsat etilgan tezlik (10-eslatma) |
[d/daq] |
1725 |
3450 |
|
|
|
|
|
|
|
|
|
|
|
| Uzluksiz nominal momentda quvvat tezligi
Standart |
[kVt/s] |
19.7 |
41.2 |
28.1 |
46.4 |
82.3 |
107 |
7.85 |
19.7 |
32.1 |
19.5 |
35.5 |
57.2 |
74.0 |
| Nominal oqim |
[A] |
2.8 |
5.2 |
7.1 |
9.4 |
13 |
19 |
2.9 |
5.6 |
9.4 |
9.6 |
14 |
22 |
26 |
| Maksimal oqim (eslatma 13) |
[A] |
9.0 |
17 |
23 |
30 |
42 |
61 |
9.0 |
17 |
29 |
31 |
45 |
70 |
83
(116) |
| Atrof-muhit (5-eslatma)
Atrof-muhit harorati |
Operatsiya |
0 °C dan 40 °C gacha (muzlatmaydigan) |
|
|
|
|
|
|
|
|
|
|
|
|
|
Saqlash |
-15 °C dan 70 °C gacha (muzlatmaydigan) |
|
|
|
|
|
|
|
|
|
|
|
|
|
Atrof-muhit namligi |
Operatsiya |
10% RH dan 80% RH (kondensatsiyalanmagan) |
|
|
|
|
|
|
|
|
|
|
|
|
|
Saqlash |
10% RH dan 90% RH (kondensatsiyalanmagan) |
|
|
|
|
|
|
|
|
|
|
|
|
| Mil uchun ruxsat etilgan yuk
(Eslatma 8) L |
[mm] |
55 |
79 |
55 |
79 |
|
|
|
|
|
|
|
|
|
|
Radial |
[N] |
980 |
2058 |
980 |
2058 |
|
|
|
|
|
|
|
|
|
|
Bosish |
[N] |
490 |
980 |
490 |
980 |
|
|
|
|
|
|
|
|
|
|
Massa (3-eslatma) Standart |
[kg] |
6.2 |
7.3 |
11 |
16 |
20 |
27 |
4.8 |
6.2 |
7.3 |
11 |
16 |
20 |
27 |
