| Mitsubishi VFD inverter |
Fr-a840-m-2-60 |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Fr-a840-00023 -01160 |
00023 |
00038 |
00052 |
00083 |
00126 |
00170 |
00250 |
00310 |
00380 |
00470 |
00620 |
00770 |
00930 |
01160 |
| Chiqish darajasi Red CW sig'imi 1
120% ortiqcha yuk sig'imi (SLD) |
0.75 |
1.5 |
2.2 |
3.7 |
5.5 |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
37 |
45 |
55 |
| 150% ortiqcha yuk sig'imi (ld) |
0.75 |
1.5 |
2.2 |
3.7 |
5.5 |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
37 |
45 |
55 |
| 200% ortiqcha yuk sig'imi (ND) |
0.4 |
0.75 |
1.5 |
2.2 |
3.7 |
5.5 |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
37 |
45 |
| 250% ortiqcha yuk sig'imi (HD) |
0.2 |
0.4 |
0.75 |
1.5 |
2.2 |
3.7 |
5.5 |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
37 |
| A
hozirgi 120% ortiqcha yuk sig'imi (SLD) Men baholadim |
2.3 |
3.8 |
5.2 |
8.3 |
12.6 |
17 |
25 |
31 |
38 |
47 |
62 |
77 |
93 |
116 |
| Men maksimal. 60 |
2.1 |
4.2 |
5.7 |
9.1 |
13.9 |
18.7 |
27.5 |
34.1 |
41.8 |
51.7 |
68.2 |
84.7 |
102.3 |
127.6 |
| Men maksimal. 3 s |
2.8 |
4.6 |
6.2 |
10.0 |
15.1 |
20.4 |
30.0 |
37.2 |
45.6 |
56.4 |
74.4 |
92.4 |
111.6 |
139.2 |
| 150% ortiqcha yuk sig'imi (ld)
Men baholadim |
2.1 |
3.5 |
4.8 |
7.6 |
11.5 |
16 |
23 |
29 |
35 |
43 |
57 |
70 |
85 |
106 |
| Men maksimal. 60 |
2.5 |
4.2 |
5.8 |
9.1 |
13.8 |
19.2 |
27.6 |
34.8 |
42.0 |
51.6 |
68.4 |
84.0 |
102.0 |
127.2 |
| Men maksimal. 3 s |
3.2 |
5.3 |
7.2 |
11.4 |
17.3 |
24.0 |
34.5 |
43.5 |
52.5 |
64.5 |
85.5 |
105.0 |
127.5 |
159.0 |
| 200% ortiqcha yuk sig'imi (ND)
Men baholadim |
1.5 |
2.5 |
4 |
6 |
9 |
12 |
17 |
23 |
31 |
38 |
44 |
57 |
71 |
86 |
| Men maksimal. 60 |
2.3 |
3.8 |
6.0 |
9.0 |
13.5 |
18.0 |
25.5 |
34.5 |
46.5 |
57.0 |
66.0 |
85.5 |
106.5 |
129.0 |
| Men maksimal. 3 s |
3.0 |
5.0 |
8.0 |
12.0 |
18.0 |
24.0 |
34.0 |
46.0 |
62.0 |
76.0 |
88.0 |
114.0 |
142.0 |
172.0 |
| 250% ortiqcha yuk sig'imi (HD) men baholadim |
0.8 |
1.5 |
2.5 |
4 |
6 |
9 |
12 |
17 |
23 |
31 |
38 |
44 |
57 |
71 |
| Men maksimal. 60 |
1.6 |
3.0 |
5.0 |
8.0 |
12.0 |
18.0 |
24.0 |
34.0 |
46.0 |
62.0 |
76.0 |
88.0 |
114.0 |
142.0 |
| Men maksimal. 3 s |
2.0 |
3.8 |
6.3 |
10.0 |
15.0 |
22.5 |
30.0 |
42.5 |
57.5 |
77.5 |
95.0 |
110.0 |
142.5 |
177.5 |
| Ortiqcha yuk hajmi 2
Sld |
60 s uchun 110% miqdorida ishlab chiqarilgan avtomobil sig'imi; 3 s uchun 120% (Maks. Atrof muhit harorati 40 ° C) - Tushunti vaqt xususiyatlari |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Ld |
60 s uchun 120% miqdorida ishlab chiqarilgan avtomobil sig'imi; 3 s uchun 150% (maksimal) 50 ° C) - Tez-teskari xususiyatlar |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nd |
60 s uchun 150% miqdorida ishlab chiqarilgan avtomobil sig'imi; 200% 3 s (maksimal) 50 ° C harorati) - Terminal vaqt xususiyatlari |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Hd |
6% 60 s ga ko'tarildi; 3 s dan 250% (maksimal) 50 ° C haroratda - teskari vaqt xususiyatlari |
|
|
|
|
|
|
|
|
|
|
|
|
|
| 3 kuchlanish |
3-fazali AC, elektr ta'minotidagi kuchlanish uchun 380-500 v |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Chastota diapazoni |
0.2-590 Hz |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nazorat usuli |
V / f; Advanced Magnit Flux vektor, haqiqiy sensorsiz vektor (RSV), yopiq pastadir vektor, pm sensorsiz vektorli nazorat |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Tormoz tranzistor 100% Ed |
O'rnatilgan |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Maksimal tormoz momenti
regenerativ |
O'rnatilgan tormozli rezistikali 100% tutun / 2% ER |
20% tutun / uzluksiz |
|
|
|
|
|
|
|
|
|
|
|
|
| Fr-Abr varianti bilan 7 |
100% moment / 10% Ed |
100% moment / 6% ed |
- |
|
|
|
|
|
|
|
|
|
|
|
| Minimal tormozga chidamlilik 6
Ō |
371 |
236 |
190 |
130 |
83 |
75 |
52 |
34 |
34 |
21 |
21 |
13.5 |
13.5 |
13.5 |
| Kirish
Elektr ta'minoti kuchlanishi |
3-fazasi, 380-500 v AC, -15% / + 10% |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Voltaj diapazoni |
323-550 V AC AC 50/60 Hz (kam ta'minlanmagan darajani parametr bilan tanlash mumkin). |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Elektr ta'minoti chastotasi |
50/60 Hz ± 5% |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Puli kiritish |
3.2 |
5.4 |
7.8 |
10.9 |
16.4 |
22.5 |
31.7 |
40.3 |
48.2 |
58.4 |
76.8 |
97.6 |
115 |
141 |
| Ld |
3 |
4.9 |
7.3 |
10.1 |
15.1 |
22.3 |
31 |
38.2 |
44.9 |
53.9 |
75.1 |
89.7 |
106 |
130 |
| Nd |
2.3 |
3.7 |
6.2 |
8.3 |
12.3 |
17.4 |
22.5 |
31 |
40.3 |
48.2 |
56.5 |
75.1 |
91 |
108 |
| Hd |
1.4 |
2.3 |
3.7 |
6.2 |
8.3 |
12.3 |
17.4 |
22.5 |
31 |
40.3 |
48.2 |
56.5 |
75.1 |
91 |
| Sovutish |
O'zini sovutish |
Fanni sovutish |
|
|
|
|
|
|
|
|
|
|
|
|
| Himoya tuzilishi 5 |
IP20 turi |
Ochiq tur (IP00) |
|
|
|
|
|
|
|
|
|
|
|
|
| Maks. Issiqlik tarqalishi i kw sld |
0.055 |
0.075 |
0.085 |
0.13 |
0.175 |
0.245 |
0.345 |
0.37 |
0.45 |
0.565 |
0.74 |
0.93 |
1.11 |
1.34 |
| Ld |
0.05 |
0.07 |
0.08 |
0.12 |
0.16 |
0.23 |
0.315 |
0.345 |
0.415 |
0.52 |
0.675 |
0.825 |
1.02 |
1.22 |
| Nd |
0.04 |
0.055 |
0.07 |
0.1 |
0.13 |
0.17 |
0.22 |
0.28 |
0.39 |
0.45 |
0.52 |
0.69 |
0.84 |
1.02 |
| Hd |
0.03 |
0.04 |
0.05 |
0.075 |
0.09 |
0.135 |
0.165 |
0.21 |
0.285 |
0.385 |
0.45 |
0.56 |
0.7 |
0.86 |
| Og'irlik kg |
2,8 |
2,8 |
2,8 |
3,3 |
3,3 |
6,7 |
6,7 |
8,3 |
8,3 |
15 |
15 |
23 |
41 |
41 |
| O'lchamlar (WXHXD)
mm |
150x260x140 |
220x260x170 |
220x300x190 |
250x400x190 |
325 × 550 X195 |
435x550x250 |
|
|
|
|
|
|
|
|
