| Tur |
Standart |
L shaklidagi |
T-Shape, SLOT CERY 7 mm |
Yaqin |
T-Shape, uyali markaz 10 mm |
F-shaklidagi |
R shaklidagi |
| Npn |
Ee-sx970-C1 |
Ee-sx971-C1 |
Ee-sx972-C1 |
Ee-sx974-c1 |
Ee-sx975-C1 |
Ee-sx976-c1 |
Ee-sx977-c1 |
| Pnp |
Ee-sx970p-c1 |
Ee-sx971p-c1 |
Ee-sx972p-c1 |
Ee-sx974p-c1 |
Ee-sx975p-c1 |
Ee-sx976p-c1 |
Ee-sx977p-c1 |
| Hikni sezgir masofa |
5 mm (uyasi kengligi) |
|
|
|
|
|
|
| His qilish ob'ekti |
Noaniq: 2 '0,8 mm min. |
|
|
|
|
|
|
| Differentsial masofa |
0.025 mm max. |
* 1 |
|
|
|
|
|
| Yorug'lik manbai (cho'qqisi - uzunligi) |
940 nm cho'qqisi bo'lgan infraqil boshliq |
|
|
|
|
|
|
| Ko'rsatkich |
Yorug'lik indikatori (to'q sariq lin) |
|
|
|
|
|
|
| Tijorat kuchlanishini ta'minlash |
5 dan 24 Vdc ± 10%, ripple (PP): 10% maksimal. |
|
|
|
|
|
|
| Hozirgi iste'mol |
21 MA MACHIB |
|
|
|
|
|
|
|
Nazorat chiqarish |
Quvvatni yuklash kuchlanishini yuklash: 5 dan 24 VDC, Yuk ko'tarish: 50 MA MAXISALAR: 0.5MA MAX,
1,0 V maksimal kuchlanish bilan 50 mlduzil elektr tok. 0,4 V maksimal kuchlanishli 5 mlnapali oqim. |
|
|
|
|
|
|
| Himoya qilish pallasi |
Quvvatni ushlab turish teskari qutblarni himoya qilish; chiqish kamera himoyasini himoya qilish; haddan tashqari olib tashlangan himoya (NPN chiqishi bilan faqat kattali2) |
|
|
|
|
|
|
| Javob chastotasi |
1 Xz min. (3 kHz o'rtacha) * 2 |
|
|
|
|
|
|
| Atrof-muhit yoritish |
1000 lx max. qabul qilgich yuzasida floresan nur bilan |
|
|
|
|
|
|
| Atrof-muhit harorati |
Operatsion: -25-dan 55 ° C gacha Saqlash: -30 dan 80 ° C gacha (muzlagichsiz) |
|
|
|
|
|
|
| Atrof-muhitning namlik darajasi |
Amalga oshirilgan: 5% dan 85% Saqlash: 5% dan 95% gacha (aralashma yoki kondensatsiz) |
|
|
|
|
|
|
| Tebranish qarshiligi (pasayish) |
X, Y va z yo'nalishlarida 10 dan 2 000 hz 0.75 mm bitta amplituda (15 minut, 10 tsikl) |
|
|
|
|
|
|
| Zarbalarga qarshi kurash (Stoklash) |
Vayronagarchilik: har bir x, y va z yo'nalishlarida 500 m / s2 |
|
|
|
|
|
|
| Himoya darajasi darajasi |
IEC 60529 IP50 |
|
|
|
|
|
|
| Ulanish usuli |
Ulagich |
|
|
|
|
|
|
| Og'irligi (qadoqlangan holat) |
Taxminan. 3 g |
|
|
|
|
|
|
| Ish / qopqoq |
Polibolilen terefalat (PBT) |
|
|
|
|
|
|
| Emitter / qabul qiluvchi |
Polikarbonat (ShK) |
|
|
|
|
|
|
