| Maqola raqami |
6GK5206-1b10--2aa3 |
6GK5206-110-2AA3 |
6GK520-0BA10--23 |
6GK5208-0-0--0--0--66 |
| Mahsulot turi belgisi |
X206-1 |
X206-1LD |
XATALANCE X208 |
X208pro |
| Transfer darajasi |
|
|
|
|
| Transfer darajasi |
10 Mbit / s, 100 Mbit / s |
10 Mbit / s, 100 Mbit / s |
10 Mbit / s, 100 Mbit / s |
10 Mbit / s, 100 Mbit / s |
| Aloqa uchun interfeyslar integratsiyalashgan |
|
|
|
|
| Elektr ulanishlari soni |
|
|
|
|
|
● Tarmoq tarkibiy qismlari yoki terminal uskunalari uchun |
6 |
6 |
8 |
8 |
| 10/100 Mbit / s rj45 portlari birlashtirilgan |
|
|
|
|
|
● yoqa bilan ta'minlash bilan |
6 |
|
8 |
|
| 10/100 Mbit / s M12-portlar (D-kodlangan) birlashtirilgan |
|
|
|
8 |
| 100 Mbit / s st (bfoc) portlari soni |
|
|
|
|
|
● MultimeMode uchun |
1 |
|
|
|
|
● bitta rejim uchun (ld) |
|
1 |
|
|
| Boshqalararo interfeyslar |
|
|
|
|
| Elektr ulanishlari soni |
|
|
|
|
|
● Kontakt signalizatsiya |
1 |
1 |
1 |
1 |
|
Kuchli elektr ta'minoti uchun ● |
1 |
1 |
1 |
1 |
|
● Ortiqcha kuchlanishli etkazib berish uchun |
1 |
1 |
1 |
1 |
| Elektr ulanish turi |
|
|
|
|
|
● Kontakt signalizatsiya |
2-qutbli terminal bloki |
2-qutbli terminal bloki |
2-qutbli terminal bloki |
5-PIN-m12 rozetkasi (B-kodlangan) |
|
Kuchli elektr ta'minoti uchun ● |
4-qutbli terminal bloki |
4-qutbli terminal bloki |
4-qutbli terminal bloki |
4-PIN M12 interfeysi (A-kodlangan) |
| Olib tashlanadigan saqlashni loyihalash |
|
|
|
|
|
● C-vilka |
Ha |
Ha |
Ha |
Ha |
| Signal Kirish / chiqish |
|
|
|
|
| Signalizatsiya kuchlarining ish kuchlanishi |
|
|
|
|
|
● DC reytingida |
24 v |
24 v |
24 v |
24 v |
| Signalizatsiya bilan aloqalarning operatsion oqimi |
|
|
|
|
|
● DCda maksimal darajada |
0,1 a |
0,1 a |
0,1 a |
0,1 a |
| Kuchlanish, joriy iste'mol, kuch yo'qotish |
|
|
|
|
| Ta'minot kuchlanishining kuchlanish turi |
Dc |
Dc |
Dc |
Dc |
| Tijorat kuchlanishini ta'minlash |
|
|
|
|
|
● Tashqi |
24 v |
24 v |
24 v |
24 v |
|
● Tashqi minimal |
18 v |
18 v |
18 v |
18 v |
|
● Tashqi maksimal |
32 |
32 |
32 |
32 |
| Mahsulot komponentini elektr tarmog'iga kiritish |
Ha |
Ha |
Ha |
Ha |
| Yuk ko'tarish kuchlanishini kiritishda sug'urta himoyasi turi |
0.6 A / 60 V |
0.6 A / 60 V |
0.6 A / 60 V |
0.6 A / 60 V |
| Hozirgi maksimal maksimal darajada iste'mol qilinadi |
0.22 a |
0,2 a |
0.185 a |
0.185 a |
| Quvvat yo'qotish [w] |
|
|
|
|
|
● DC da 24 v |
5.28 w |
5.28 w |
3.84 |
4.4 |
| Atrof-muhit sharoitlari |
|
|
|
|
| Atrof-muhit harorati |
|
|
|
|
|
● Ish paytida |
-40 ... +60 ° C |
-40 ... +60 ° C |
-40 ... +60 ° C |
-40 ... +70 ° C |
|
● Saqlash paytida |
-40 ... +70 ° C |
-40 ... +70 ° C |
-40 ... +70 ° C |
-40 ... +70 ° C |
|
● Transport paytida |
-40 ... +70 ° C |
-40 ... +70 ° C |
-40 ... +70 ° C |
-40 ... +70 ° C |
| Nisbiy namlik |
|
|
|
|
|
● Ishlash paytida 25 ° C da kondensatsiya paytida |
95% |
95% |
95% |
95% |
| Himoyachilar IP |
Qaysar |
Qaysar |
Qaysar |
IP65 / 67 |
