| Model Name | DOP-B10S411 | DOP-B10S511 | DOP-B10E515 |
| LCD MODULE
Display Type | 10.1” Widescreen TFT LCD
(65536 colors) | 10.4” TFT LCD
(65536 colors) | 10.4” TFT LCD
(65536 colors) |
|
Resolution | 800 x 480 pixels | 800 x 600 pixels | 800 x 600 pixels |
|
Backlight | LED Back Light (less than 20,000 hours half-life at 25oC) (Note 1) |
|
|
|
Display Size | 219.6 x 131.76mm | 211.2 x 158.4mm | 211.2 x 158.4mm |
| Operation System | Delta Real Time OS |
|
|
| MCU | 32-bit RISC Micro-controller |
|
|
| Flash ROM | Flash ROM 128 MB
(OS System: 30MB / Backup: 16MB / User Application: 82MB) |
|
|
| SDRAM | 64Mbytes |
|
|
| Backup Memory | 32Kbytes |
|
|
| Audio Output
Buzzer | Multi-Tone Frequency (2K ~ 4K Hz) / 85dB |
|
|
|
AUX | N/A | Stereo Output |
|
|
Ethernet Interface | N/A | IEEE 802.3, IEEE 802.3u |
|
|
N/A | 10/100 Mbps auto-sensing (has
built-in isolated power circuit (Note 3) ) |
|
| Memory Card | N/A | SD Card (supports SDHC) |
|
| USB | 1 USB Slave Ver 2.0
1 USB Host (Note 2) Ver 1.1 |
|
|
|
Serial COM Port COM1 | RS-232 (supports hardware flow control) |
|
|
|
COM2 |
RS-232/485 |
RS-232/485 | RS-232/422/485
(has built-in isolated power circuit (Note 3) ) |
|
COM3 |
RS-232/422/485 |
RS-232/422/485 | RS-232/422/485
(has built-in isolated power circuit (Note 3) ) |
| Perpetual Calendar (RTC) | Built-in |
|
|
| Cooling Method | Natural air circulation |
|
|
| Safety Approval | UL (Note 4) / CE (Note 4) |
|
|
| Waterproof Degree | IP65 |
|
|
| Operation Voltage
(Note3) | DC +24V (-10% ~ +15%) |
|
|
| Voltage Endurance | AC500V for 1 minute
(between charging (DC24V terminal) and FG terminals) |
|
|
| Power Consumption
(Note 3) | 6.6W | 6.1W | 9.6W |
| Backup Battery | 3V lithium battery CR2032 × 1 |
|
|
| Backup Battery Life | It depends on the temperature used and the conditions of usage,
about 3 years or more at 25oC. |
|
|
| Operation Temperature | o o
0 C ~ 50 C |
|
|
| Storage Temperature | o o
-20 C ~ +60 C |
|
|
| Ambient Humidity | o o
10% ~ 90% RH [0 ~ 40 C], 10% ~ 55% RH [41 ~ 50 C] Pollution Degree 2 |
|
|
| Vibration | IEC 61131-2 compliant 5Hz≦f＜8.3Hz = Continuous: 3.5mm, 8.3Hz≦f
≦150Hz = Continuous: 1.0g |
|
|
| Shock | IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions for 6 times |
|
|
| Dimensions
(W) x (H) x (D) mm | 272 x 200 x 61 | 299 x 224 x 46.8 | 299 x 224 x 46.8 |
| Panel Cutout
(W) x (H) mm | 261.3 X 189.3 | 285.2 x 210.2 | 285.2 x 210.2 |
| Weight | Approx. 1520g | Approx. 1735g | Approx. 1600g |
