| Model | DOP-B08S515 | DOP-B08E515 |
| LCD MODULE
Display Type | 8” TFT LCD
(65536 colors) |
| Resolution | 800 x 600 pixels |
| Backlight | LED Back Light (less than 10,000 hours half-life at 25oC) (Note 1) |
| Display Size | 162 x 121.5mm |
| Operation
System | Delta Real Time OS |
| MCU | 32-bit RISC Micro-controller |
| NOR Flash ROM | Flash ROM 128 MB(OS System: 30MB / Backup: 16MB / User Application: 82MB) |
| SDRAM | 64Mbytes |
| Backup Memory | 16Mbytes |
| Sound
Effect Output Buzzer | Multi-Tone Frequency（2K ~ 4K Hz）／85dB |
|
AUX | N/A | Stereo output |
|
Ethernet Interface |
N/A | IEEE 802.3, IEEE 802.3u |
|
| 10/100 Mbps
auto-sensing(has built-in isolated power circuit (Note 3)） |
| USB | 1 USB Host (Note 2) Ver 1.1 / 1 USB Slave Ver 2.0 |
| Memory Card | SD Card (supports SDHC) |
| Serial COM Port COM1 | RS-232 (supports hardware flow control) |
|
COM2 | RS-232／RS-422／RS-485 | RS-232 / RS-422 / RS-485
(has built-in isolated power circuit (Note 3)) |
|
COM3 | RS-232／RS-422／RS-485 | RS-232 / RS-422 / RS-485
(has built-in isolated power circuit (Note 3)) |
| Function Key | N/A |
| Perpetual Calendar (RTC) | Built-in |
| Cooling Method | Natural air circulation |
| Safety Approval | CE／UL (Note 4) ／KCC (Note 4) |
| Waterproof Degree | IP65／NEMA4 |
| Operation Voltage (Note 5) | DC +24V (-10% ~ +15%)
(please use isolated power supply) | DC +24V (-10% ~ +15%)
(has built-in isolated power circuit (Note 3)) |
| Voltage Endurance | AC500V for 1 minute (between charging (DC24V terminal) and FG terminals) |
| Power Consumption (Note 5) |
5.2W |
7.8W |
| Backup Battery | 3V lithium battery CR2032 x 1 |
| Backup Battery Life | It depends on the temperature used and the conditions of usage, about 3 years or
more at 25oC. |
| Operation Temp. | o o
0 C ~ 50 C |
| Storage Temp. | o o
-20 C ~ +60 C |
