| MODEL | DOP-B07
S415 | DOP-B07
E415 | DOP-B07
PS415 | DOP-B07
S515 | DOP-B07
E515 | DOP-B07
PS515 |
| Display Type | 7” Widescreen TFT LCD (65536 colors) | 7” TFT LCD
(65536 colors) |
| Resolution | 800 x 480 pixels | 800 x 600 pixels |
| Backlight | LED Back Light (less than 20,000 hours
half-life at 25oC) (Note 1) | LED Back Light (less than 10,000 hours
half-life at 25oC) (Note 1) |
| Display Size | 152.4 x 91.44mm | 141 x 105.75mm |
| Operation System | Delta Real Time OS |
| MCU | 32-bit RISC Micro-controller |
|
NOR Flash ROM | Flash ROM 128 MB
(OS System: 30MB / Backup: 16MB / User Application: 82MB) |
| SDRAM | 64Mbytes |
| Backup Memory | 16Mbytes |
| Sound Effect Output
Buzzer | Multi-Tone Frequency（2K ~ 4K Hz）／85dB |
|
AUX | N/A | Stereo output | N/A | N/A | Stereo output | N/A |
|
| IEEE 802.3, IEEE 802.3u |
|
| IEEE 802.3, IEEE 802.3u |
|
|
Ethernet Interface |
N/A | 10/100 Mbps auto-sensing (has built-in isolated power circuit
(Note 3)） |
N/A |
N/A | 10/100 Mbps auto-sensing (has built-in isolated power circuit (Note 3)） |
N/A |
| USB | 1 USB Host (Note 2) Ver 1.1 /
1 USB Slave Ver 2.0 |
| Memory Card | SD Card (supports SDHC) |
|
COM1 |
RS-232 (supports hardware flow control) |
|
| RS-232／ |
|
|
|
|
|
Serial COM Port COM2 |
RS-232／ RS-422／ RS-485 | RS-422／ RS-485
(has built-in isolated power circuit (Note 3)） |
RS-232／ RS-422／ RS-485 |
RS-232／ RS-485 | RS-232 / RS-485
(has built-in isolated power circuit (Note 3)) |
RS-232／ RS-485 |
|
| RS-232／ |
|
|
|
|
|
COM3 |
RS-232／ RS-422／ RS-485 | RS-422／ RS-485
(has built-in isolated power circuit |
RS-232／ RS-422／ RS-485 |
RS-422／ RS-485 | RS-422 / RS-485
(has built-in isolated power circuit (Note 3)) |
RS-422／ RS-485 |
|
| (Note 3)） |
|
|
|
|
| Function Key | N/A |
| Perpetual Calendar (RTC) | Built-in |
| Cooling Method | Natural air circulation |
| Safety Approval | CE／UL (Note 4) ／KCC (Note 4) |
| Waterproof Degree | IP65／NEMA4 |
|
| DC +24V |
|
|
|
|
|
Operation Voltage (Note 5) | DC +24V
（-10% ~ +15%） (please use isolated power supply) | （-10% ~
+15%） （has built-in isolated power circuit (Note 3)） | DC +24V
（-10% ~ +15%） (please use isolated power supply) | DC +24V (-10% ~
+15%) (please use isolated power supply) | DC +24V (-10% ~
+15%) (has built-in isolated power circuit (Note 3)) | DC +24V (-10% ~
+15%) (please use isolated power supply) |
| Voltage Endurance | AC500V for 1 minute (between charging (DC24V terminal) and FG terminals) |
| Power Consumption
(Note 5) | 5W | 7.5W | 5W | 7.68W |
| Backup Battery | 3V lithium battery CR2032 x 1 |
| Backup Battery Life | It depends on the temperature used and the conditions of usage, about 3 years or more at 25oC. |
| Operation Temp. | o o
0 C ~ 50 C |
| Storage Temp. | o o
-20 C ~ +60 C |
| Ambient Humidity | 10% ~ 90% RH [0 ~ 40oC], 10% ~ 55% RH [41 ~ 50oC]
Pollution Degree 2 |
| Vibration | IEC 61131-2 compliant 5Hz≦f＜8.3Hz = Continuous: 3.5mm, 8.3Hz≦f≦150Hz = Continuous: 1.0g |
| Shock | IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions for 6 times |
| Dimensions
(W) x (H) x (D) mm | 215 x 161 x 50 | 184 x 144 x 50 |
| Panel Cutout
(W) x (H) mm | 196.9 x 142.9 | 172.4 x 132.4 |
| Weight | Approx.970g | Approx.800g |
