| Model | DOP-B05S111 |
| LCD MODULE
Display Type | 5.6” TFT LCD
(65536 colors) |
| Resolution | 320 x 234 pixels |
|
Backlight | LED Back Light (less than 20,000 hours half-life at 25oC) (Note 1) |
| Display Size | 113.28 x 84.70mm |
| Operation System | Delta Real Time OS |
| MCU | 32-bit RISC Micro-controller |
|
NOR Flash ROM | Flash ROM 128 MB
(OS System: 30MB / Backup: 16MB / User Application: 82MB) |
| SDRAM | 64Mbytes |
| Backup Memory | 16Mbytes |
|
Sound Effect Output Buzzer | Multi-Tone Frequency（2K ~ 4K Hz）／85dB |
| Ethernet Interface |
N/A |
| USB | 1 USB Host (Note 2) Ver 1.1 / 1 USB Slave Ver 2.0 |
| Memory Card | N/A |
| Serial COM Port
COM1 | RS-232 (supports hardware flow control) |
| COM2 | RS-232／RS-485 |
| COM3 | RS-422／RS-485 |
| Function Key | N/A |
| Perpetual Calendar (RTC) | Built-in |
| Cooling Method | Natural air circulation |
| Safety Approval | CE／UL (Note 3) ／KCC (Note 3) |
| Waterproof Degree | IP65／NEMA4 |
| Operation Voltage
(Note 4) | DC +24V（-10% ~ +15%）(please use isolated power supply) |
| Voltage Endurance | AC500V for 1 minute (between charging (DC24V terminal) and FG terminals) |
| Power Consumption (Note 4) | 3.0W |
| Backup Battery | 3V lithium battery CR2032 x 1 |
| Backup Battery Life | It depends on the temperature used and the conditions of usage, about 3 years or more at 25oC. |
| Operation Temp. | o o
0 C ~ 50 C |
| Storage Temp. | o o
-20 C ~ +60 C |
| Ambient Humidity | 10% ~ 90% RH [0 ~ 40oC], 10% ~ 55% RH [41 ~ 50oC]
Pollution Degree 2 |
| Vibration | IEC 61131-2 compliant 5Hz≦f＜8.3Hz = Continuous: 3.5mm, 8.3Hz≦f≦
150Hz = Continuous: 1.0g |
| Shock | IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions for 6 times |
| Dimensions
(W) x (H) x (D) mm | 184 x 144 x 50 |
| Panel Cutout
(W) x (H) mm | 172.4 x 132.4 |
| Weight | Approx.670g |
