| Model | SH-416 | SH-422*2 | SH-430*2 | SH-440*2 | SH-290*2 | SH-809*2 | SH-816*2 | SH-822*2 | SH-108 |
| Type | Standard Non-shielded Cylindrical & Threaded | Standard Non-shielded Cylindrical | Heat-resistant*3 Shielded Cylindrical | Heat-resistant*3 Shielded Threaded | Heat-resistant*3 Non-shielded Cylindrical &
Threaded | Oil-resistant*4 Shielded Threaded |
| Shape | ø14.5×20 Cylindrical ＋ Threaded | ø22×35 Cylindrical ＋ Threaded | ø30×45 Cylindrical ＋ Threaded | ø40×55 Cylindrical ＋ Threaded | ø90×30 Cylindrical | ø9.4×18 Cylindrical | M16×20 Threaded | ø22×35 Cylindrical ＋ Threaded | M8×25 Threaded |
| Detectable object | Ferrous metal (see Characteristics for nonferrous metals) |
| Standard target (iron, t=1 mm <font color=”#0099ff”>0.04″</font>) | 20 x 20 mm 0.79″ x 0.79″*1 | 25 x 25 mm 0.98″ x 0.98″*1 | 30 x 30 mm 1.18″ x 1.18″*1 | 40 x 40 mm 1.57″*1 | 150 x 150 mm
5.91″ x 5.91″*1 | 15 x 15 mm 0.59″ x 0.59″*1 | 20 x 20 mm 0.79″ x 0.79″*1 | 30 x 30 mm 1.18″ x 1.18″*1 | 10 x 10 mm 0.39″ x 0.39″*1 |
| Stable detecting range | 0 to 6 mm 0.24″ | 0 to 9 mm 0.35″ | 0 to 12 mm 0.47″ | 0 to 18 mm 0.71″ | 0 to 35 mm 1.38″ | 0.5 to 2 mm
0.02″ to 0.08″ | 1 to 4 mm
0.04″ to 0.16″ | 2 to 8 mm
0.08″ to 0.31″ | 0 to 2 mm 0.08″ |
| Maximum detecting distance | 15 mm 0.59″ | 22 mm 0.87″ | 30 mm 1.18″ | 40 mm 1.57″ | 70 mm 2.76″ | ― | 3.5 mm 0.14″ |
| Repeatability | 0.005 mm 0.0002″*1 | 0.008 mm 0.0003″*1 | 0.01 mm 0.0004″*1 | 0.015 mm 0.0006″*1 | 0.03 mm 0.001″*1 | 0.002 mm
0.00008″*1 | 0.005 mm 0.0002″*1 | 0.008 mm 0.0003″*1 | 0.002 mm 0.00008″*1 |
| Hysteresis | 0.015 mm 0.0006″*1 | 0.02 mm 0.0008″*1 | 0.03 mm 0.001″*1 | 0.05 mm 0.0002″*1 | 0.1 mm 0.004″*1 | 0.04 mm 0.002″*1 | 0.05 mm 0.002″*1 |
| Temperature characteristics | 0.08%/°C*1 | 0.2%/°C*1 |
| Enclosure rating | IP67 | Heat-resistant | Oil-resistant |
| Ambient temperature | -10 to +60 °C 14 to 140 °F (No freezing) | -10 to +200 °C 14 to 392 °F (No freezing) | -10 to +60 °C 14 to 140 °F (No freezing) |
| Relative humidity | 35 to 85 % RH (No condensation) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Weight | Approx. 73 g | Approx. 195 g | Approx. 225 g | Approx. 280 g | Approx. 650 g | Approx. 55 g | Approx. 83 g | Approx. 170 g | Approx. 45 g |
