Sick Photoelectric sensors GTB2S-N1311 GTB2S-N1331

Series#: Sick Photoelectric sensors

Sick Photoelectric sensors GTB2S-N1311 GTB2S-N1331
We can Supply all kinds of Sick sensor parts,such as Sick Capacitive Proximity Sensors,Sick Contrast Sensors,Sick Fork Sensors,Sick Magnetic Proximity Sensors,Sick Photoelectric Sensors,Sick Distance Sensors and Sick Fiber Sensors.
All parts are 100% Original and new in stock by Sick and fast delivery time within 1 day
100% after sale service and technology Support
MOQ: 1pcs

Availability:



Inquire

Product Description

Series#: Sick Photoelectric sensors

Sick Photoelectric sensors GTB2S-N1311 GTB2S-N1331
We can Supply all kinds of Sick sensor parts,such as Sick Capacitive Proximity Sensors,Sick Contrast Sensors,Sick Fork Sensors,Sick Magnetic Proximity Sensors,Sick Photoelectric Sensors,Sick Distance Sensors and Sick Fiber Sensors.

Download a Munual

Sensor/ detection principle	Photoelectric proximity sensor, Background suppression
Dimensions (W x H x D)	7.7 mm x 21.8 mm x 13.5 mm
Housing design (light emission)	Rectangular
Sensing range max.	1 mm … 18 mm 1)
Sensing range	4 mm … 15 mm 2)
Background suppression typ. from	20 mm
Type of light	Visible red light
Light source	PinPoint LED 3)
Light spot size (distance)	Ø 2 mm (8 mm)
Wave length	640 nm
Adjustment	None
Special applications	Detecting small objects

Supply voltage	10 V DC … 30 V DC 1)
Ripple	≤ 5 Vpp 2)
Current consumption	20 mA 3)
Switching output	NPN
Switching mode	Light switching
Output current Imax.	< 50 mA
Response time	< 0.6 ms 4)
Switching frequency	800 Hz 5)
Connection type	Cable, 3-wire, 2 m 6)
Cable material	PVC
Cable diameter	Ø 3 mm
Circuit protection	A 7) C 8) D 9)
Weight	33.7 g
Housing material	Plastic, ABS
Optics material	Plastic, PMMA
Enclosure rating	IP67
Ambient operating temperature	–25 °C … +50 °C
Ambient storage temperature	–40 °C … +75 °C
UL File No.	NRKH.E181493

Relevant documents

dataSheet_GTB2S-N1311_1062840_en.pdf
