The Siemens SIMATIC ET 200SP DI 8x24VDC HF (6ES7131-6BF00-0BA0) is a compact high-feature digital input module for the ET 200SP distributed I/O system. It provides 8 channels of 24V DC digital input with configurable input delay from 0.05 to 0.6 ms, hardware interrupt capability on both rising and falling edges, and comprehensive diagnostics including wire break and short circuit detection. The module supports 1-wire connections and is compatible with Type A0 and A1 Base Units. Suitable for general-purpose digital signal acquisition in manufacturing automation, machine control, and process skid applications. The High Feature designation indicates advanced diagnostic and interrupt capabilities beyond basic digital input modules.
FAQ
Q:Q: How many input channels does this module have?
A: 8 channels of 24V DC digital input. Q: Does this module support hardware interrupts?
A: Yes, it supports hardware interrupts on both rising and falling edges. Q: What diagnostics are available?
A: Wire break detection and short circuit to L+ detection. Q: What is the configurable input delay range?
A: From 0.05 ms to 0.6 ms. Q: What BaseUnit types are compatible?
A: Type A0 and Type A1 Base Units.
