TENGEN TGJC1-62Z Mini Electromagnetic Relay



Series#:  Relay->TENGEN Relays



  • TENGEN TGJC1-62Z Mini Electromagnetic Relay
  • We have Large inventory for all Eaton Circuit Breakers,eaton circuit breaker panels,eaton circuit breaker enclosure,eaton circuit breaker accessories,eaton c series circuit breakers,eaton e frame circuit breaker, eaton circuit breaker faz and ect.
  • 100% Original and new,In stock by Eaton Company.
  • Delivery time: Ready in stock and 1 days for ship out
  • MOQ: 1pcs
Availability:
Inquire

  • TGJC1-62Z

  • TENGEN

Product Description

Series#: Relay->TENGEN Relays


Parameter Specification
Contact form 2Z(C)
Initial contact resistance 100mΩ
Contact material Silver alloy
Contact load (COSΦ=1.0) 10A (220VAC/28VDC)
Max. switching voltage 250VAC/125VDC
Max. switching current 10A
Max. switching power 2200VA/280W
Electrical life 3.5x10^4 times
Mechanical life 2x10^7 times
Insulation resistance 100MΩ (500VDC)
Medium withstand voltage 1500VAC (between contact coils/sets), 1000VAC (between break contacts)
Action time ≤20ms
Release time ≤20ms
Shock (stability) 10G
Vibration Double amplitude 1mm, (10~55)Hz
Outgoing terminal form Plug-in type, PCB type
Dimensions (mm) 27.5x21.5x35.5
Rated power DC: 0.9W, AC: 1.2VA
Coil Operating Voltage DC: ≤75% of rated voltage; AC: ≤80% of rated voltage
Coil Release Voltage DC: ≥10% of rated voltage; AC: ≥30% of rated voltage
Coil Rated Voltage (AC) 6V, 9V, 12V, 18V, 24V, 36V, 48V, 50V, 60V, 110V, 127V, 220V
Coil Rated Voltage (DC) 6V, 9V, 12V, 18V, 24V, 36V, 48V, 60V, 110V




Relevant documents
download TENGEN_TGJC1-62Z.pdf
