| Memory | Flash | 4 GB |
| RAM | 1 GB |
| Processor |
| 32-bit RISC Cortex-A9 1GHz (Two 2D Graphics Engine) |
|
I/O Port | SD Card Slot | N/A |
| USB Host | USB 2.0 x 1 |
| USB Client | N/A |
| Ethernet | LAN 1: 10/100/1000 Base-T x 1
LAN 2: 10/100 Base-T x 1 |
| COM Port | COM1: RS-232 COM2: RS-485 2W/4W
COM3: RS-485 2W |
| RS-485 Dual Isolation | N/A |
| CAN Bus | N/A |
| HDMI Output | Resolution 1920 x 1080 (customizable) |
| Audio Output | HDMI Audio Output |
| Video Input | N/A |
| RTC |
| Built-in |
|
Power | Input Power | 10.5~28VDC |
| Power Isolation | Built-in |
| Power Consumption | 1250mA@12VDC；550mA@24VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW at 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
|
Specification | PCB Coating | Yes |
| Enclosure | Plastic |
| Dimensions WxHxD | 29.8 x 130 x 115 mm |
| Weight | Approx. 0.24 kg |
| Mount | 35mm DIN rail mounting |
|
Environment | Protection Structure | IP20 |
| Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| Certificate | CE | CE marked |
| UL | cULus Listed |
| Software |
| EasyBuilder Pro V6.02.01 or later versions |
