Weintek PLC HMI cMT-G01

Supports OPCUA,MQTT, MODBUS TCP/IPGateway
Compact Design and DIN-railMountable,Fan-less Cooling System
Built-in 256 MB FlashMemory,Supports MPI5K,Built-in Power Isolator
Weintek PLC HMI cMT-G01
We can Supply Weintek HMI touch screen all series ,such as Weinteck HMI CMT Series ,Weinteck HMI eMT Series,Weinteck HMI iE Series ,Weinteck HMI iER Series ,Weinteck HMI iP Series,Weinteck HMI mTV Series and Weinteck HMI XE Series .
100% Original and new,In stock by Weintek Labs Inc.
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Product Description

Supports OPCUA,MQTT, MODBUS TCP/IPGateway
Compact Design and DIN-railMountable,Fan-less Cooling System
Built-in 256 MB FlashMemory,Supports MPI5K,Built-in Power Isolator
Weintek PLC HMI cMT-G01
We can Supply Weintek HMI touch screen all series ,such as Weinteck HMI CMT Series ,Weinteck HMI eMT Series,Weinteck HMI iE Series ,Weinteck HMI iER Series ,Weinteck HMI iP Series,Weinteck HMI mTV Series and Weinteck HMI XE Series .

Memory	Flash	256 MB
	RAM	256 MB
Processor		32 bits RISC Cortex-A8 600MHz
I/O Port	SD Card Slot	N/A
	USB Host	N/A
	USB Client	N/A
	Ethernet (LAN1)	10/100/1000 Base-T x 1
	Ethernet (LAN2)	10/100 Base-T x 1
	COM Port	COM1: RS-232 2W COM2: RS-485 2W/4W COM3: RS-485 2W
	RS-485 Dual Isolation	N/A
	CAN Bus	N/A
	HDMI	N/A
	Audio Output	N/A
	Video Input	N/A
RTC		Built-in
Power	Input Power	24±20%VDC
	Power Isolation	Built-in
	Power Consumption	230mA@24VDC
	Voltage Resistance	500VAC (1 min.)
	Isolation Resistance	Exceed 50MW at 500VDC
	Vibration Endurance	10 to 25Hz (X, Y, Z direction 2G 30 minutes)
Specification	PCB Coating	Yes
	Enclosure	Plastic
	Dimensions WxHxD	109 x 81 x 27 mm
	Weight	Approx. 0.14 kg
	Mount	35 mm DIN rail mounting
Environment	Protection Structure	IP20
	Storage Temperature	-20° ~ 60°C (-4° ~ 140°F)
	Operating Temperature	0° ~ 50°C (32° ~ 122°F)
	Relative Humidity	10% ~ 90% (non-condensing)
Certificate	CE	CE marked
	UL	cULus Listed
Software		EasyBuilder Pro V5.06.01 or later versions EasyAccess 2.0 (Optional)
