| Models | SP-5600WA |
| Part Number | PFXSP5600WAD | PFXSP5600WADF0C |
| Conformal Coating | – | Yes |
| Input Voltage | 12-24 Vdc (limits 10.8 -29.9 Vdc) |
| Voltage Drop | 12 Vdc: 1.25 ms or less/ 24 Vdc: 5 ms or less |
| In-Rush Current | 30 A or less |
| Voltage Endurance | 1,000 Vac, 20 mA for 1 minute (between charging and FG terminals) |
| Insullation Resistance | 500 Vdc, 10 MQ or more (between charging and FG terminals) |
| Power Consumption*1 | 11.5W (max), 2.5 or less (When screen turns off the backlight (Standby Mode), 6W or less (when screen backlight 20%) |
| Surrounding Air Temerpature | 0…60 °C [32…140 °F] |
| Storage Temperature | -20…60 °C [-4…140 °F] |
| Certifications | CE, RoHS, GOST-R, UL/c-UL, KC |
| Ratings*2 | IP66F, IP67F, TYPE 4X (Indoor Use Only)/13 (on the front panel when properly installed in an enclosure), ANSI/ISA 12.12.0 1, UL508, EN61000- 6-4, EN61000-6-2, Class 1 Div 2 Groups A, B, C, and D |
| Surrounding Air and Storage Humidity | 10%…90% RH (Non condensing, wet bulb temperature 39 °C [102.2 °F] or less) |
| Dust | 0.1 mg/m3 (10-7 oz/ft3) or less (non-conductive levels) |
| Pollution Degree | For use in Pollution Degree 2 environment |
| Corrosive Gas | Free of corrosive gases |
| Atmospheric Pressure (Operating Altitude) | 800…1,114 hPa (2,000 m [6,561 ft] or lower) |
| Vibration and Shock Resistance | IEC/EN 61131-2 compliant |
| Electrostatic Discharge Immunity | Contact Discharge Method: 6 kV (IEC/EN 61000-4-2 Level 3) |
| Weight*4 | 3kg (6.6 lb) or less |
| External Dimensions*3 | W308.5 x H230.5 x D67mm (W12.15 x H9.07 x D2.64 in.) |
| Panel Cut Dimensions | W295 x H217 mm (W11.61 x H8.54 in.) |
