| Fodelith |
EM-030 |
EM-038 |
Em-005 |
EM-054 |
EM-080 |
EM-010 |
EM-014 |
| Theipia ’ |
Cysgodol |
|
|
|
|
|
|
| Siapid |
3 mm 0.12 ″ dia silindrog. |
3.8 mm 0.15 ″ silindrog dia. |
M5 Threaded |
5.4 mm 0.21 ″ silindrog dia. |
8 mm 0.31 ″ dia silindrog. |
M10 Threaded |
M14 Threaded |
| Canfod pellter |
0.6 mm 0.02 ″ ± 15% |
0.8 mm 0.031 ″ ± 15% |
1.0 mm 0.04 ″ ± 15% |
1.2 mm 0.05 ″ ± 10% |
2.0 mm 0.08 ″ ± 10% |
4.0 mm 0.16 ″ ± 10% |
|
| Gwrthrych canfyddadwy |
Metelau fferrus (gweler y nodweddion ar gyfer metelau anfferrus) |
|
|
|
|
|
|
Targed safonol
(haearn, t = 1 mm 0.04 ″ ) |
5 x 5 mm 0.20 ″ |
6 x 6 mm 0.24 ″ |
10 x 10 mm 0.39 ″ x 0.39 ″ |
15 x 15 mm 0.59 ″ x 0.59 ″ |
|
|
|
| Hysteresis |
10% ar y mwyaf. o ganfod pellter |
|
|
|
|
|
|
| Amledd Ymateb |
1.2 kHz |
|
|
|
|
|
|
| Modd gweithredu |
Na |
|
|
|
|
|
|
| Nodweddion tymheredd |
± 10% ar y mwyaf. o ganfod pellter ar +23 ° C 73.4 ° F, o fewn -10 i +70 ° C 14 i 158 ° F. |
|
|
|
|
|
|
| Dangosydd arddangos |
COCH LED |
|
|
|
|
|
|
| Allbwn |
Npn |
|
|
|
|
|
|
| Allbwn rheoli |
NPN: 200 Ma (40 V) Max., Foltedd gweddilliol: 1 V ar y mwyaf. |
|
|
|
|
|
|
| Nhai |
Dur gwrthstaen |
Pres CR-plated |
|
|
|
|
|
|
Foltedd |
10.8 i 30 VDC, crychdonni (PP) 10 % neu lai*1 |
|
|
|
|
|
|
| Defnydd cyfredol |
12 ma neu lai |
|
|
|
|
|
|
| Sgôr Amgaead |
Ip67 |
|
|
|
|
|
|
| Tymheredd Amgylchynol |
-25 i +80 ° C -13 i 176 ° F (dim rhewi) |
|
|
|
|
|
|
| Lleithder cymharol |
35 i 95 % RH (dim anwedd) |
|
|
|
|
|
|
| Mhwysedd |
Tua. 36 g (gan gynnwys cnau a chebl 2-m 6.6 ′) |
Tua. 38 g (gan gynnwys cnau a chebl 2-m 6.6 ′) |
Tua. 40 g (gan gynnwys cnau a chebl 2-m 6.6 ′) |
Tua. 42 g (gan gynnwys cnau a chebl 2-m 6.6 ′) |
Tua. 50 g (gan gynnwys cnau a chebl 2-m 6.6 ′) |
Tua. 60 g (gan gynnwys cnau a chebl 2-m 6.6 ′) |
|
