| Item |
Descriptiones |
| Item |
C14 |
C30 |
C60 |
| Nullam output type |
DC input: 8, Nullam output: 6 |
DC input: 16, Nullam output: 14 |
DC input: 32, Nullam output: 28 |
| Transistor output type |
DC input: 8, transistor output: 6 |
DC input: 16, transistor output: 14 |
DC input: 32, transistor output: 28 |
| Maximilianus. I / O puncta, cum expanditur |
254 puncta (328 puncta max. cum usura addendi in reta et FP0R expansion unitates) |
270 puncta (352 puncta max. cum usura addendi in reta et FP0R ) expansionem unitates |
300 puncta (382 puncta max. cum usura addendi in reta et FP0R expansion unitates) |
| Programmandi modum / modum Imperium |
Nullam figuram / Cyclic operation |
| Programma memoria |
Inaedificata mico ROM (non tergum altilium requiritur) |
| Facultas Program |
16 k gradibus |
32 k gradibus |
32 k gradibus |
| Operatio celeritas |
Instructio fundamentalis: 0.32 µs~/gradus |
| I/O refice + basi tempus |
0.2 ms [Cum usura FP0R expansionis unitatum: 1 ms + (1.5 Numeri expansionis unitates) ms] |
| Externa initibus (X) |
1,760 puncta (numerus punctorum actualis per ferramenta restringitur). |
| Externi outputs (F) |
1,760 puncta (numerus punctorum actualis per ferramenta restringitur). |
| Nullam internus (X) |
4,096 puncta (R0 ad R255F) |
| Specialis Nullam internam (R) |
192 puncta |
| Timor / counter (T/C) |
1,024 puncta: timer capax numerandi (1 ms, 10 ms, 100 ms, 1 sec.) × 32,767, Rationes numerandi capaces 1 ad 32,767 |
| Nullam Link (L) |
2,048 puncta |
| Data actis mandare |
12,285 verba (DT0 ad DT12284) |
32.765 verba (DT0 ad DT32764) |
| Specialis notitiae actis mandare (DT) |
374 words |
| Vinculum subcriptio (LD) |
256 words |
| Index registri (I) |
14 words |
|
Summus celeritate contra (Nota I) |
Inaedificata (Transistor output): unum tempus 8 ch (50 kHz 4 ch + 10 kHz × 4 ch) inaedificatum (Nullam output): unum tempus 8 ch (10 kHz × 8 ch)
Pulsus I/O cassette: una-phase 2 ch (80 kHz × 2 ch) |
| Pulsus output (nota 2) / PWM output |
Inaedificata (Transistor output): 100 kHz × 2 ch + 20 kHz × 2 ch.
Pulsus I/O cassette: Una unitas (axis unius) 100 kHz, vel duae unitates (duae axes) 80 kHz |
| Tempus measurement |
10 μs anulus contra |
| Potentiometer |
2 puncta (K0 ad K1000) |
2 puncta (K0 ad K1000) |
IV puncta (K0 ad K1000) |
| Constans scan |
Praesto |
| Horologium / calendarium |
Cum AFPX-MRTC adiungitur: Annus (duobus proximis digitis), mensis, dies, horae (24-horas ostensionis), minuta, secunda, dies hebdomadis. Operatur solum cum altilium installatur. |
| Tergum per P13 mandata |
Data actis mandare (32,765 verba) |
| Auto-tergum in potentia deficiendi |
Contra 16 puncta (1008 ad 1023), CURSUS INTERNUS 128 puncta (R2480 ad R255F);
Litterae datae verba 55 ( C30 / C60 = 32710 ad 32764, C14 = 12230 ad 12284); |
| Pugna tergum |
Memoria in tabulario in tabulario systematis partita (tantum cum altilium installatur) |
