| GP-2401 Series | GP-2501 Series | GP-2601 Series |
|
Type | TFT type color LCD | GP-2501L
Monochrome LCD | TFT type color LCD |
| Type | TFT type color LCD | GP-2501S
STN type color LCD | TFT type color LCD |
| Type | TFT type color LCD | GP-2501T
TFT type color LCD | TFT type color LCD |
|
Colors | 256 / No blink*1,
64 colors / 3-speed blink (Color switching is done via software) | GP-2501L
Black and White, 2 levels of gray/ 8 levels of gray*2 (Color switching is done via software) | 256 / No blink*1,
64 colors / 3-speed blink (Color switching is done via software) |
|
Colors | 256 / No blink*1,
64 colors / 3-speed blink (Color switching is done via software) | GP-2501S
64 colors / 3-speed blink | 256 / No blink*1,64 colors / 3-speed blink (Color switching is done via software) |
|
Colors | 256 / No blink*1,
64 colors / 3-speed blink (Color switching is done via software) | GP-2501T
256 / No blink*1, 64 colors / 3-speed blink (Color switching is done via software) | 256 / No blink*1,64 colors / 3-speed blink (Color switching is done via software) |
| Resolution | 640 x 480pixels | 800 x 600pixels |
|
| Effective Display Area | W149.8mm [5.90in.] x
H112.3mm [4.42in.] | W211.2mm [8.34in.] x
H158.4mm [6.24in.] | W246mm [9.69in.] x
H184.5mm [7.26in.] |
|
Language Fonts | ASCII: (Code page 850) Alphanumeric (incl. Eur. characters) Chinese: (GB2312-80 codes) simplified Chinese fonts Japanese: ANK 158, Kanji : 6962 (JIS Standards 1 & 2) Korean: (KSC5601 – 1992 codes) Hangul fonts
Taiwanese: (Big 5 codes) traditional Chinese fonts |
|
|
| 8×8 dots | 80 Char. x 60 rows | 100 Char. x 75 rows |
|
| 8×16 dots | 80 Char. x 30 rows | 100 Char. x 37 rows |
|
| 16×16 dots | 40 Char. x 30 rows | 50 Char. x 37 rows |
|
| 32×32 dots | 20 Char. x 15 rows | 25 Char. x 18 rows |
|
| Font Sizes | Hight can be expanded 1 to 8 times.
Width can be expanded 1/2*4, 1 to 8 times. |
|
|
| Character Sizes *3 | 8X8 dot font, 8X16 dot font, 16X16 dot font and 32X32 dot font |
|
|
| Backlight | CCFL (Service life: 50,000 hrs. at 25oC and 24hr. operation) |
|
|
| Brightness Control | 4 levels of adjustment available via touch panel. |
|
|
