| Items | Specifications |
| CE marking directive compliance | Low Voltage Directive, EMC Directive, RoHS Directive |
| Operating temperature | 0 to +55 °C +32 to +131 °F |
| Storage temperature | −40 to +70 °C −40 to +158 °F |
| Operating humidity | 10 to 95% RH (at +25 °C +77 °F, no dew condensation allowed) |
| Storage humidity | 10 to 95% RH (at +25 °C +77 °F, no dew condensation allowed) |
Withstand voltage (Note 1,2) | Input terminals Relay output terminals |
2,300 V AC, 1 minute |
| All of the transistor output terminals All of the relay output terminals |
|
| All of the input terminals All of the power supply terminals and functional ground terminals |
|
| All of the relay output terminals All of the power supply terminals and functional ground terminals |
|
| All of the transistor output terminals All of the power supply terminals and functional ground terminals |
|
| Power supply terminals Ground terminals | 1,500 V AC, 1 minute |
| Input terminals Transistor output terminals | 500 V AC, 1 minute |
Insulation resistance (Note 1) | Input terminals Output terminals |
100 MΩ min. (500 V DC insulation resistance meter) |
| All of the transistor output terminals All of the relay output terminals |
|
| All of the input terminals All of the power supply terminals and functional ground terminals |
|
| All of the output terminals All of the power supply terminals and functional ground terminals |
|
| Power supply terminals Ground terminals |
|
Vibration resistance | 5 to 8.4 Hz, 3.5 mm 0.138 in amplititude in one direction, 1 scan/1 minute
8.4 to 150 Hz, fixed acceleration of 9.8 m/s2, 1 scan/1 minute 10 minutes in X, Y, Z direction each |
| Shock resistance | 147 m/s2, 4 times in X, Y, Z directions each |
| Noise immunity | 1,500 V [p-p] pulse width 50 ns, 1 μs (Measured from nosie simulation method AC power supply termianls) |
| Operating environment | No corrosive gases or too much dust |
| Overvoltage class |
|
| Pollution level | 2 |
| Net weight | L14R: 280 g approx., L30R: 450 g approx., L40R / L40MR: 530 g approx., L60R / L60MR: 730 g approx. |
