| Article number | 6ES7450-1AP01-0AE0 |
| FM 450-1, COUNTER MODULE, 2 CHANNELS |
| Supply voltage |
|
| Auxiliary voltage 1L+, load voltage 2L+ |
|
|
● Rated value (DC) | 24 V |
|
● permissible range, lower limit (DC) | 20.4 V; Dynamic 18.5 V |
|
● permissible range, upper limit (DC) | 28.8 V; dynamic 30.2 V |
| Input current |
|
| from load voltage 1L+ (without load), max. | 50 mA |
| from load voltage 2L+ (without load), max. | 60 µA |
| from backplane bus 5 V DC, max. | 300 mA |
| Encoder supply |
|
| 5 V encoder supply |
|
|
● 5 V | Yes; 5.2 V ±2 % |
|
● Short-circuit protection | Yes |
|
● Output current, max. | 300 mA |
| 24 V encoder supply |
|
|
● 24 V | Yes; 1L+ (-3 V) |
|
● Short-circuit protection | Yes |
|
● Output current, max. | 300 mA |
| Power loss |
|
| Power loss, typ. | 6 W |
| Digital inputs |
|
| Number of digital inputs | 6 |
| Functions | 1 for gate start, 1 for gate stop, 1 for setting the counter |
| Input voltage |
|
|
● for signal “0” | -28.8 … +5V |
|
● for signal “1” | +11 to +28.8V |
| Input current |
|
|
● for signal “1”, typ. | 9 mA |
| Input delay (for rated value of input voltage) |
|
|
● Input frequency (with a time delay of 0.1 ms), max. | 200 kHz |
| for standard inputs |
|
|
— parameterizable | Yes |
|
— at “0” to “1”, max. | 2.5 µs; ≥ 2.5 µs (200 kHz); ≤ 25 µs (20 kHz) |
| Digital outputs |
|
| Number of digital outputs | 4 |
| Short-circuit protection | Yes; Clocked electronically |
| Limitation of inductive shutdown voltage to | 2L+ (-39 V) |
| Output voltage |
|
|
● for signal “0”, max. | 3 V |
|
● for signal “1”, min. | 2L+ (-1,5 V) |
| Output current |
|
|
● for signal “1” rated value | 0.5 A; Res. / P.D. 5 W tungsten 24 V DC |
|
● for signal “1” permissible range for 0 to 60 °C, min. | 5 mA |
|
● for signal “1” permissible range for 0 to 60 °C, max. | 0.6 A |
| Output delay with resistive load |
|
|
● “0” to “1”, max. | 300 µs |
| Encoder |
|
| Connectable encoders |
|
|
● Incremental encoder (symmetrical) | Yes; With 2 pulse trains offset by 90° |
|
● Incremental encoder (asymmetrical) | Yes |
|
● 24 V initiator | Yes |
|
● 24 V directional element | Yes; 1 pulse train, 1 direction level |
| Interrupts/diagnostics/status information |
|
| Status indicator | Yes; 14 green LEDs for status of CR, DIR, inputs and outputs |
| Diagnostics function | Yes |
| Alarms |
|
|
● Diagnostic alarm | Yes; Parameterizable |
|
● Hardware interrupt | Yes; Parameterizable |
| Diagnoses |
|
|
● Diagnostic information readable | Yes |
| Diagnostics indication LED |
|
|
● internal fault INTF (red) | Yes |
|
● external fault EXTF (red) | Yes |
|
● Status indicator digital input (green) | Yes |
|
● Status indicator digital output (green) | Yes |
| Counter |
|
| Number of counter inputs | 2; 32 bit or ±31 bit |
| Counter input 5 V |
|
|
● Type | RS 422 |
|
● Terminating resistor | 220 Ω |
|
● Differential input voltage | min. 0.5 V |
|
● Counting frequency, max. | 500 kHz |
| Counter input 24 V |
|
|
● Input voltage for signal “0” | -30 to +5 V |
|
● Input voltage for signal “1” | +11 to +30V |
|
● Input current for signal “1”, typ. | 9 mA |
|
● Counting frequency, max. | 200 kHz |
|
● Minimum pulse width | ≥ 2.5 µs (200 kHz); ≥ 25 µs (20 kHz) (parameterizable) |
| Potential separation |
|
| Potential separation digital inputs |
|
|
● between the channels and backplane bus | Yes; Optocoupler |
| Potential separation digital outputs |
|
|
● between the channels and backplane bus | Yes; Optocoupler |
| Potential separation counter |
|
|
● between the channels and backplane bus | Yes; Optocoupler |
| Isolation |
|
| Isolation tested with | 500 V |
| Connection method |
|
| required front connector | 1x 48-pin |
| Dimensions |
|
| Width | 25 mm |
| Height | 290 mm |
| Depth | 210 mm |
| Weights |
|
| Weight, approx. | 650 g |
