| Display | 15” IPS |
| Resolution | 1024 x 768 |
| Brightness (cd/m2) | 400 |
| Contrast Ratio | 1000:1 |
| Backlight Type | LED |
| Backlight Life Time | >50,000 hrs. |
| Colors | 16.2M |
| LCD Viewing Angle (T/B/L/R) | 89/89/89/89 |
| Pixel Pitch (mm) | 0.297(H)x0.297(V) |
| Type | 4-wire Resistive Type |
| Accuracy | Active Area Length(X)±2%, Width(Y)±2% |
| Flash | 256 MB |
| RAM | 256 MB |
| Processor | 32-bit RISC 1GHz |
| SD Card Slot | SD/SDHC |
| USB Host | USB 2.0 x 1 |
| USB Client | USB 2.0 x 1 |
| Ethernet | 10/100 Base-T x 1 |
| COM Port | COM1: RS-232/RS-485 2W/4W COM3: RS-485 2W |
| RS-485 Dual Isolation | Yes |
| RTC | Built-in |
| Input Power | 24±20%VDC |
| Power Isolation | Built-in |
| Power Consumption | 1.2A@24VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW @ 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating | Yes |
| Enclosure | Aluminum |
| Dimensions WxHxD | 366 x 293 x 57 mm |
| Panel Cutout | 352 x 279 mm |
| Weight | Approx. 2.75 kg |
| Mount | Panel mount, VESA mount 75 x 75 mm |
| Protection Structure | UL Type 4X (indoor use only) / NEMA4 / IP65 Compliant Front Panel |
| Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| CE | CE marked |
| ATEX | ATEX Zone 2/22 Category 3 G/D |
| UL | cULus Listed |
| Software | EasyBuilder Pro V4.00.01 or later versions |
