| Display | 4.3” TFT LCD |
| Resolution | 480 x 272 |
| Brightness (cd/m2) | 400 |
| Contrast Ratio | 500:1 |
| Backlight Type | LED |
| Backlight Life Time | >30,000 hrs. |
| Colors | 16.7M |
| LCD Viewing Angle (T/B/L/R) | 50/70/70/70 |
| Type | 4-wire Resistive Type |
| Accuracy | Active Area Length(X)±2%, Width(Y)±2% |
| Flash | 128 MB |
| RAM | 128 MB |
| Processor | 32 Bits RISC Cortex-A8 600MHz |
| USB Host | USB 2.0 x 1 |
| USB Client | N/A |
| Ethernet | 10/100 Base-T x 1 |
| COM Port | COM1 RS-232/RS-485 2W/4W COM3 RS-485 2W |
| RS-485 Dual Isolation | N/A |
| RTC | Built-in (CR2032 3V lithium battery.) |
| Input Power | 10.5~28VDC |
| Power Consumption | 800mA@12VDC ; 400mA@24VDC |
| Power Isolation | Built-in |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MΩ at 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating | N/A |
| Enclosure | Plastic |
| Dimensions WxHxD | 128 x 102 x 32 mm |
| Panel Cutout | 119 x 93 mm |
| Weight | Approx. 0.25 kg |
| Mount | Panel mount |
| Protection Structure | NEMA4 / IP65 Compliant Front Panel |
| Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10~90% (non-condensing) |
| CE | CE marked |
| Software | EasyBuilder Pro |
