| Display | 21.5” IPS |
| Resolution | Full HD 1920 x 1080 |
| Brightness (cd/m2) | 250 |
| Contrast Ratio | 1000:1 |
| Backlight Type | LED |
| Backlight Life Time | >50,000 hrs. |
| Colors | 16.7M |
| LCD Viewing Angle (T/B/R/L) | 89/89/89/89 |
| Pixel Pitch (mm) | 0.2479 (H) x 0.2479 (V) |
| Type | Tempered Glass, Capacitive Type (Supports 2-Finger Gestures) |
| Hardness Scale | 6H |
| Flash | N/A |
| RAM | N/A |
| Processor | N/A |
| SD Card Slot | N/A |
| USB Host | USB 2.0 x 1 |
| USB Client | USB 2.0 x 1 (Micro USB) |
| HDMI | Yes (Video Input) |
| Audio Output | N/A |
| RTC | N/A |
| Input Power | 24±20%VDC |
| Power Isolation | Built-in |
| Power Consumption | 1.56A@24VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW at 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating | Yes |
| Enclosure | Aluminum |
| Dimensions WxHxD | 546 x 354 x 56.2 mm |
| Panel Cutout | 532 x 340 mm |
| Weight | Approx. 4.9 kg |
| Mount | Panel mount, VESA mount 100 x 100 mm |
| Protection Structure | NEMA4 / IP65 Compliant Front Panel |
| Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| CE | CE marked |
| UL | cULus Listed |
| Display | N/A |
