Memory | Flash | 4 GB |
| RAM | 512 MB |
| Data, Memory, Code | 3 MB |
| Retain area | 16 KB (every minute) (Kept after reboots) |
| Persistent area | 16 KB (every minute) (Kept after downloads) |
| File system | 8MB |
| Processor |
| Dual-Core 32 bits RISC 1GHz |
|
I/O Port | SD Card Slot | SD/SDHC |
| Ethernet | Ethernet 1: 10/100/1000 Base-T x 1
Ethernet 2: 10/100 Base-T x 1 |
| COM Port | COM1 RS-232 2W, COM2 RS-485 2W/4W, COM3 RS-485 2W |
| Local bus | iBus |
| CAN Bus | N/A |
| CODESYS | Protocol | Modbus TCP/IP Master |
| RTC |
| Built-in |
|
Power | Input Power | 24±20%VDC |
| Power Isolation | Built-in |
| Power Dissipation | Nominal 310mA＠24VDC |
| Current for Internal Bus | Max 2A＠5VDC |
| Current Consumption | 550mA＠5VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW @ 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
|
Specification | PCB Coating | Yes |
| Enclosure | Plastic |
| Dimensions WxHxD | 50 x 109 x 81 mm |
| Weight | Approx. 0.24 kg |
| Mount | 35 mm DIN rail mounting |
|
Environment | Protection Structure | IP20 |
| Storage Temperature | -20° ~ 70°C (-4° ~ 158°F) |
| Operating Temperature | -10° ~ 50°C (14° ~122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| Certificate | CE | CE marked |
| Software |
| EasyBuilder Pro V6.03.02 or later versions CODESYS V3.5 SP10 Patch 3 or later |
