| Model | cMT3103 |
| Display | 10.1” TFT |
| Resolution | 1024 x 600 |
| Brightness (cd/m2) | 350 |
| Contrast Ratio | 500:1 |
| Backlight Type | LED |
| Backlight Life Time | >50,000 hrs. |
| Colors | 16.7M |
| LCD Viewing Angle (T/B/L/R) | 60/60/70/70 |
| Type | 4-wire Resistive Type |
| Accuracy | Active Area Length(X)±2%, Width(Y)±2% |
| Flash | 4 GB |
| RAM | 1 GB |
| 32 bits RISC Cortex-A9 1GHz |
| SD Card Slot | N/A |
| USB Host | USB 2.0 x 1 |
| USB Client | N/A |
| Ethernet | 10/100 Base-T x 1 |
|
WiFi | IEEE 802.11 b/g/n 802.11b: max 19.25 dBm 802.11g: max 13.74 dBm
802.11n: max 15.01 dBm |
| COM Port | Con.A:COM2 RS-485 2W/4W,COM3 RS-485 2W,CAN Bus
Con.B: COM1/COM3 RS-232* |
| RS-485 Dual Isolation | N/A |
| CAN Bus | Yes |
| Audio Output | N/A |
| Video Input | N/A |
| Built-in |
| Input Power | 10.5~28VDC |
| Power Isolation | Built-in |
| Power Consumption | 2A@12V ; 1A@24V |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW at 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating | Yes |
| Enclosure | Plastic |
| Dimensions WxHxD | 271 x 213 x 36.4 mm |
| Panel Cutout | 260 x 202 mm |
| Weight | Approx. 1.07 kg |
| Mount | Panel mount |
| Protection Structure | NEMA4 / IP65 Compliant Front Panel |
| Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| CE | CE marked |
| UL | cULus Listed |
| EasyBuilder Pro V6.00.02 or later versions |
