| Yaskawa sigma-7 servopacks sgd7s- |
R70F |
R90f |
2r1f |
2R8F |
| Kapasitas motorik maksimum yang berlaku [KW] |
0.05 |
0.1 |
0.2 |
0.4 |
| Arus keluaran kontinu [lengan] |
0.66 |
0.91 |
2.1 |
2.8 |
| Arus keluaran maksimum sesaat [lengan] |
2.1 |
3.2 |
6.5 |
9.3 |
| Kontrol Catu Daya |
100 VAC hingga 120 VAC, -15% hingga +10%, 50/60 Hz |
| Kapasitas Catu Daya [KVA]* |
0.2 |
0.3 |
0.6 |
1.4 |
| Resistor regeneratif
Resistensi eksternal minimum yang diijinkan [w] |
40 |
40 |
40 |
40 |
| Kategori tegangan tegangan |
AKU AKU AKU |
| Yaskawa Sigma-7 Servopacks |
R70a |
R90a |
1r6a |
2R8A |
3R8A |
5r5a |
7r6a |
120a |
180a |
200a |
330a |
| Kapasitas motorik maksimum yang berlaku [KW] |
0.05 |
0.1 |
0.2 |
0.4 |
0.5 |
0.75 |
1.0 |
1.5 |
2.0 |
3.0 |
5.0 |
| Arus keluaran kontinu [lengan] |
0.66 |
0.91 |
1.6 |
2.8 |
3.8 |
5.5 |
7.6 |
11.6 |
18.5 |
19.6 |
32.9 |
| Arus keluaran maksimum sesaat [lengan] |
2.1 |
3.2 |
5.9 |
9.3 |
11 |
16.9 |
17 |
28 |
42 |
56 |
84.0 |
| Kontrol Catu Daya |
200 VAC hingga 240 VAC, -15% hingga +10%, 50 Hz/60 Hz |
| Kapasitas Catu Daya [KVA]* |
0.2 |
0.3 |
0.5 |
1.0 |
1.3 |
1.6 |
2.3 |
3.2 |
4.0 |
5.9 |
7.5 |
|
Kehilangan Daya Sirkuit Utama [W] |
5.1 |
7.3 |
13.5 |
24.0 |
20.1 |
43.8 |
53.6 |
65.8 |
111.9 |
113.8 |
263.7 |
| Kontrol Kehilangan Daya Sirkuit [W] |
17 |
17 |
17 |
17 |
17 |
17 |
17 |
22 |
22 |
22 |
27 |
| Kehilangan daya resistor regeneratif bawaan [W] |
- - |
- - |
- - |
- - |
8 |
8 |
8 |
10 |
16 |
16 |
36.0 |
| Total kehilangan daya [w] |
22.1 |
24.3 |
30.5 |
41.0 |
45.1 |
68.8 |
78.6 |
97.8 |
149.9 |
151.8 |
326.7 |
| Yaskawa Sigma-7 Servopacks Model SGD7S- |
470a |
550a |
590a |
780a |
| Kapasitas motorik maksimum yang berlaku [KW] |
6.0 |
7.5 |
11 |
15 |
| Arus keluaran kontinu [lengan] |
46.9 |
54.7 |
58.6 |
78.0 |
| Arus keluaran maksimum sesaat [lengan] |
110 |
130 |
140 |
170 |
| Yaskawa sigma-7 servopacks sgd7s- |
R70a |
R90a |
1r6a |
2R8A |
5r5a |
| Kapasitas motorik maksimum yang berlaku [KW] |
0.05 |
0.1 |
0.2 |
0.4 |
0.75 |
| Arus keluaran kontinu [lengan] |
0.66 |
0.91 |
1.6 |
2.8 |
5.5 |
| Arus keluaran maksimum sesaat [lengan] |
2.1 |
3.2 |
5.9 |
9.3 |
16.9 |
| Kontrol Catu Daya |
200 VAC hingga 240 VAC, -15% hingga +10%, 50 Hz/60 Hz |
| Kapasitas Catu Daya [KVA]* |
0.2 |
0.3 |
0.6 |
1.2 |
1.9 |
| Yaskawa sigma-7 servopacks sgd7s- |
R70a |
R90a |
1r6a |
2R8A |
3R8A |
5r5a |
7r6a |
120a |
| Kapasitas motorik maksimum yang berlaku [KW] |
0.05 |
0.1 |
0.2 |
0.4 |
0.5 |
0.75 |
1.0 |
1.5 |
| Arus keluaran kontinu [lengan] |
0.66 |
0.91 |
1.6 |
2.8 |
3.8 |
5.5 |
7.6 |
11.6 |
| Arus keluaran maksimum sesaat [lengan] |
2.1 |
3.2 |
5.9 |
9.3 |
11.0 |
16.9 |
17.0 |
28.0 |
| Kontrol Catu Daya |
270 VDC hingga 324 VDC, -15% hingga +10% |
| Kapasitas Catu Daya [KVA]* |
0.2 |
0.3 |
0.6 |
1 |
1.4 |
1.6 |
2.3 |
3.2 |
| Yaskawa sigma-7 servopacks sgd7s- |
180a |
200a |
330a |
470a |
550a |
590a |
780a |
| Kapasitas motorik maksimum yang berlaku [KW] |
2.0 |
3.0 |
5.0 |
6.0 |
7.5 |
11.0 |
15.0 |
| Arus keluaran kontinu [lengan] |
18.5 |
19.6 |
32.9 |
46.9 |
54.7 |
58.6 |
78.0 |
| Arus keluaran maksimum sesaat [lengan] |
42.0 |
56.0 |
84.0 |
110 |
130 |
140 |
170 |
| Kontrol Catu Daya |
270 VDC hingga 324 VDC, -15% hingga +10% |
| Kapasitas Catu Daya [KVA]* |
4.0 |
5.9 |
7.5 |
10.7 |
14.6 |
21.7 |
29.6 |
