Article number | 6ES7212-1AF40-0XB0 | 6ES7212-1HF40-0XB0 | 6ES7214-1AF40-0XB0 | 6ES7214-1HF40-0XB0 | 6ES7215-1AF40-0XB0 | 6ES7215-1HF40-0XB0 |
| CPU 1212FC ,DC/DC/DC, 8DI/6DO/2AI | CPU 1212FC, DC/DC/Relay, 8DI/6DO/2AI | CPU 1214 FC, DC/DC/DC, 14DI/10DO/2AI | CPU 1214 FC, DC/DC/Relay, 14DI/10DO/2AI | CPU 1215 FC, DC/DC/DC, 14DI/10DO/2AI/2AO | CPU 1215 FC, DC/DC/RLY,14DI/10DO/2AI/2AO |
General information |
|
|
|
|
|
|
Product type designation | CPU 1212FC DC/DC/DC | CPU 1212FC DC/DC/relay | CPU 1214FC DC/DC/DC | CPU 1214FC DC/DC/Relay | CPU 1215FC DC/DC/DC | CPU 1215FC DC/DC/relay |
|
Firmware version | V4.2 | V4.2 | V4.2 | V4.2 | V4.2 | V4.2 |
|
Engineering with |
|
|
|
|
|
|
·
● Programming package · | STEP 7 V14 or higher | STEP 7 V14 or higher | STEP 7 V14 or higher | STEP 7 V14 or higher | STEP 7 V14 or higher | STEP 7 V14 or higher |
|
Output current |
|
|
|
|
|
|
for backplane bus (5 V DC), max. | 1 000 mA; Max. 5 V DC for SM and CM | 1 000 mA; Max. 5 V DC for SM and CM | 1 600 mA; Max. 5 V DC for SM and CM | 1 600 mA; Max. 5 V DC for SM and CM | 1 600 mA; Max. 5 V DC for SM and CM | 1 600 mA; Max. 5 V DC for SM and CM |
|
Encoder supply |
|
|
|
|
|
|
24 V encoder supply |
|
|
|
|
|
|
·
● 24 V · | Permissible range: 20.4V to 28.8V | Permissible range: 20.4V to 28.8V | L+ minus 4 V DC min. | L+ minus 4 V DC min. | L+ minus 4 V DC min. | L+ minus 4 V DC min. |
|
Power loss |
|
|
|
|
|
|
Power loss, typ. | 9 W | 9 W | 12 W | 12 W | 12 W | 12 W |
|
Memory |
|
|
|
|
|
|
Work memory |
|
|
|
|
|
|
·
● integrated · | 100 kbyte | 100 kbyte | 125 kbyte | 125 kbyte | 150 kbyte | 150 kbyte |
|
·
● expandable · | No | No | No | No | No | No |
|
Load memory |
|
|
|
|
|
|
·
● integrated · | 2 Mbyte | 2 Mbyte | 4 Mbyte | 4 Mbyte | 4 Mbyte | 4 Mbyte |
|
·
● Plug-in (SIMATIC Memory Card), max. · | with SIMATIC memory card | with SIMATIC memory card | with SIMATIC memory card | with SIMATIC memory card | with SIMATIC memory card | with SIMATIC memory card |
|
CPU-blocks |
|
|
|
|
|
|
Number of blocks (total) | DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used | DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used | DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used | DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used | DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used | DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used |
|
OB |
|
|
|
|
|
|
·
● Number, max. · | Limited only by RAM for code | Limited only by RAM for code | Limited only by RAM for code | Limited only by RAM for code | Limited only by RAM for code | Limited only by RAM for code |
|
Data areas and their retentivity |
|
|
|
|
|
|
Retentive data area (incl. timers, counters, flags), max. | 10 kbyte | 10 kbyte | 10 kbyte | 10 kbyte | 10 kbyte | 10 kbyte |
|
Flag |
|
|
|
|
|
|
·
● Number, max. · | 4 kbyte; Size of bit memory address area | 4 kbyte; Size of bit memory address area | 8 kbyte; Size of bit memory address area | 8 kbyte; Size of bit memory address area | 8 kbyte; Size of bit memory address area | 8 kbyte; Size of bit memory address area |
|
Local data |
|
|
|
|
|
|
·
● per priority class, max. · | 16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB | 16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB | 16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB | 16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB | 16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB | 16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB |
|
Cable length |
|
|
|
|
|
|
·
● shielded, max. · | 100 m; twisted and shielded | 100 m; twisted and shielded | 100 m; twisted and shielded | 100 m; twisted and shielded | 100 m; twisted and shielded | 100 m; twisted and shielded |
|
·
— Updating time · | The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data. | The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data. | The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data. | The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data. | The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data. | The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data. |
|
PROFIBUS | Yes; CM 1243-5 (master) or CM 1242-5 (slave) required | Yes; CM 1243-5 (master) or CM 1242-5 (slave) required | Yes; CM 1243-5 (master) or CM 1242-5 (slave) required | Yes; CM 1243-5 (master) or CM 1242-5 (slave) required | Yes; CM 1243-5 (master) or CM 1242-5 (slave) required | Yes; CM 1243-5 (master) or CM 1242-5 (slave) required |
|
AS-Interface | Yes; CM 1243-2 required | Yes; CM 1243-2 required | Yes; CM 1243-2 required | Yes; CM 1243-2 required | Yes; CM 1243-2 required | Yes; CM 1243-2 required |
|
Vibrations |
|
|
|
|
|
|
·
● Vibration resistance during operation acc. to IEC 60068-2-6 · | 2 g (m/s²) wall mounting, 1 g (m/s²) DIN rail | 2 g (m/s²) wall mounting, 1 g (m/s²) DIN rail | 2 g (m/s²) wall mounting, 1 g (m/s²) DIN rail | 2 g (m/s²) wall mounting, 1 g (m/s²) DIN rail | 2 g (m/s²) wall mounting, 1 g (m/s²) DIN rail | 2 g (m/s²) wall mounting, 1 g (m/s²) DIN rail |
|
·
● Operation, tested according to IEC 60068-2-6 · | Yes | Yes | Yes | Yes | Yes | Yes |
|
Shock testing |
|
|
|
|
|
|
·
● tested according to IEC 60068-2-27 · | Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms | Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms | Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms | Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms | Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms | Yes; IEC 68, Part 2-27 half-sine: strength of the shock 15 g (peak value), duration 11 ms |
|
Pollutant concentrations |
|
|
|
|
|
|
·
● SO2 at RH < 60% without condensation · | S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60% condensation-free | S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60% condensation-free | S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60% condensation-free | S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60% condensation-free | S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60% condensation-free | S02: < 0.5 ppm; H2S: < 0.1 ppm; RH < 60% condensation-free |
|
Dimensions |
|
|
|
|
|
|
Width | 90 mm | 90 mm | 110 mm | 110 mm | 130 mm | 130 mm |
|
Height | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
|
Depth | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
|
Weights |
|
|
|
|
|
|
Weight, approx. | 370 g | 385 g | 435 g | 435 g | 585 g | 585 g |
|
