| Model |
SH-416 |
SH-422*2 |
SH-430*2 |
SH-440*2 |
SH-290*2 |
SH-809*2 |
SH-816*2 |
SH-822*2 |
SH-108 |
| Type |
Standard Non-shielded Cylindrical & Threaded |
Standard Non-shielded Cylindrical |
Heat-resistant*3 Shielded Cylindrical |
Heat-resistant*3 Shielded Threaded |
Heat-resistant*3 Non-shielded Cylindrical &
Threaded |
Oil-resistant*4 Shielded Threaded |
|
|
|
| Shape |
ø14.5×20 Cylindrical ＋ Threaded |
ø22×35 Cylindrical ＋ Threaded |
ø30×45 Cylindrical ＋ Threaded |
ø40×55 Cylindrical ＋ Threaded |
ø90×30 Cylindrical |
ø9.4×18 Cylindrical |
M16×20 Threaded |
ø22×35 Cylindrical ＋ Threaded |
M8×25 Threaded |
| Detectable object |
Ferrous metal (see Characteristics for nonferrous metals) |
|
|
|
|
|
|
|
|
| Standard target (iron, t=1 mm <font color=”#0099ff”>0.04″</font>) |
20 x 20 mm 0.79″ x 0.79″*1 |
25 x 25 mm 0.98″ x 0.98″*1 |
30 x 30 mm 1.18″ x 1.18″*1 |
40 x 40 mm 1.57″*1 |
150 x 150 mm
5.91″ x 5.91″*1 |
15 x 15 mm 0.59″ x 0.59″*1 |
20 x 20 mm 0.79″ x 0.79″*1 |
30 x 30 mm 1.18″ x 1.18″*1 |
10 x 10 mm 0.39″ x 0.39″*1 |
| Stable detecting range |
0 to 6 mm 0.24″ |
0 to 9 mm 0.35″ |
0 to 12 mm 0.47″ |
0 to 18 mm 0.71″ |
0 to 35 mm 1.38″ |
0.5 to 2 mm
0.02″ to 0.08″ |
1 to 4 mm
0.04″ to 0.16″ |
2 to 8 mm
0.08″ to 0.31″ |
0 to 2 mm 0.08″ |
| Maximum detecting distance |
15 mm 0.59″ |
22 mm 0.87″ |
30 mm 1.18″ |
40 mm 1.57″ |
70 mm 2.76″ |
― |
3.5 mm 0.14″ |
|
|
| Repeatability |
0.005 mm 0.0002″*1 |
0.008 mm 0.0003″*1 |
0.01 mm 0.0004″*1 |
0.015 mm 0.0006″*1 |
0.03 mm 0.001″*1 |
0.002 mm
0.00008″*1 |
0.005 mm 0.0002″*1 |
0.008 mm 0.0003″*1 |
0.002 mm 0.00008″*1 |
| Hysteresis |
0.015 mm 0.0006″*1 |
0.02 mm 0.0008″*1 |
0.03 mm 0.001″*1 |
0.05 mm 0.0002″*1 |
0.1 mm 0.004″*1 |
0.04 mm 0.002″*1 |
0.05 mm 0.002″*1 |
|
|
| Temperature characteristics |
0.08%/°C*1 |
0.2%/°C*1 |
|
|
|
|
|
|
|
|
Enclosure rating |
IP67 |
Heat-resistant |
Oil-resistant |
|
|
|
|
|
|
| Ambient temperature |
-10 to +60 °C 14 to 140 °F (No freezing) |
-10 to +200 °C 14 to 392 °F (No freezing) |
-10 to +60 °C 14 to 140 °F (No freezing) |
|
|
|
|
|
|
| Relative humidity |
35 to 85 % RH (No condensation) |
|
|
|
|
|
|
|
|
| Vibration resistance |
10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
|
|
|
|
|
|
|
|
| Weight |
Approx. 73 g |
Approx. 195 g |
Approx. 225 g |
Approx. 280 g |
Approx. 650 g |
Approx. 55 g |
Approx. 83 g |
Approx. 170 g |
Approx. 45 g |
