Sick Photoelectric sensors GTE6-N1211

Series#: Sick Photoelectric sensors

Sick Photoelectric sensors GTE6-N1211
We can Supply all kinds of Sick sensor parts,such as Sick Capacitive Proximity Sensors,Sick Contrast Sensors,Sick Fork Sensors,Sick Magnetic Proximity Sensors,Sick Photoelectric Sensors,Sick Distance Sensors and Sick Fiber Sensors.
All parts are 100% Original and new in stock by Sick and fast delivery time within 1 day
100% after sale service and technology Support
MOQ: 1pcs

Availability:



Inquire

Product Description

Series#: Sick Photoelectric sensors

Sick Photoelectric sensors GTE6-N1211
We can Supply all kinds of Sick sensor parts,such as Sick Capacitive Proximity Sensors,Sick Contrast Sensors,Sick Fork Sensors,Sick Magnetic Proximity Sensors,Sick Photoelectric Sensors,Sick Distance Sensors and Sick Fiber Sensors.

Download a Munual

Sensor/ detection principle	Photoelectric proximity sensor, Energetic
Dimensions (W x H x D)	12 mm x 31.5 mm x 21 mm
Housing design (light emission)	Rectangular
Sensing range max.	≤ 300 mm 1)
Sensing range	≤ 250 mm
Type of light	Visible red light
Light source	PinPoint LED 2)
Light spot size (distance)	Ø 7 mm (90 mm)
Wave length	650 nm
Adjustment	Mechanical spindle, 5 turns

Supply voltage	10 V DC … 30 V DC 1)
Ripple	± 10 % 2)
Current consumption	30 mA 3)
Switching output	NPN
Switching mode	Light/dark switching
Switching mode selector	Selectable via light/dark selector
Signal voltage NPN HIGH/LOW	Approx. VS / ≤ 3 V
Output current Imax.	≤ 100 mA 4)
Response time	< 1,250 µs 5)
Switching frequency	500 Hz 6)
Connection type	Cable, 3-wire, 2 m 7)
Cable material	PVC
Conductor cross-section	0.14 mm²
Circuit protection	A 8) B 9) D 10)
Protection class	III
Weight	60 g
Housing material	Plastic, ABS/PC
Optics material	Plastic, PMMA
Enclosure rating	IP67
Ambient operating temperature	–25 °C … +55 °C 11)
Ambient storage temperature	–40 °C … +70 °C
UL File No.	NRKH.E348498 & NRKH7.E348498

Relevant documents

dataSheet_GTE6-N1211_1050713_en.pdf
