Home » Products » HMI » Weintek HMI » Weintek HMI cMT-G02

Product Category

Share to:

Weintek HMI cMT-G02

Series#: Weintek HMI

Supports OPC UA,MQTT,MODBUS TCP/IP Gateway
We can Supply Weintek HMI touch screen all series ,such as Weinteck HMI CMT Series ,Weinteck HMI eMT Series,Weinteck HMI iE Series ,Weinteck HMI iER Series ,Weinteck HMI iP Series,Weinteck HMI mTV Series and Weinteck HMI XE Series .
100% Original and new,In stock by Weintek Labs Inc.
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Availability:



Inquire

Product Description

Series#: Weintek HMI

Supports OPC UA,MQTT,MODBUS TCP/IP Gateway
We can Supply Weintek HMI touch screen all series ,such as Weinteck HMI CMT Series ,Weinteck HMI eMT Series,Weinteck HMI iE Series ,Weinteck HMI iER Series ,Weinteck HMI iP Series,Weinteck HMI mTV Series and Weinteck HMI XE Series .

Download a Munual

Flash	256 MB
RAM	256 MB
Processor	32 bits RISC Cortex-A8 600MHz
SD Card Slot	N/A
USB Host	N/A
USB Client	N/A
Ethernet	10/100 Base-T x 1
WiFi	IEEE 802.11 b/g/n 802.11b: max 15.88 dBm 802.11g: max 11.92 dBm 802.11n: max 11.28 dBm
COM Port	COM1: RS-232 2W COM2: RS-485 2W/4W COM3: RS-485 2W
RS-485 Dual Isolation	N/A
CAN Bus	N/A
HDMI	N/A
Audio Output	N/A
Video Input	N/A
RTC	Built-in
Input Power	10.5~28VDC
Power Isolation	Built-in
Power Consumption	230mA@12VDC;115mA@24VDC
Voltage Resistance	500VAC (1 min.)
Isolation Resistance	Exceed 50MW at 500VDC
Vibration Endurance	10 to 25Hz (X, Y, Z direction 2G 30 minutes)
PCB Coating	Yes
Enclosure	Plastic
Dimensions WxHxD	109 x 81 x 27 mm
Weight	Approx. 0.14 kg
Mount	35 mm DIN rail mounting
Protection Structure	IP20
Storage Temperature	-20° ~ 60°C (-4° ~ 140°F)
Operating Temperature	0° ~ 50°C (32° ~ 122°F)
Relative Humidity	10% ~ 90% (non-condensing)
CE	CE marked
UL	cULus Listed
Software	EasyBuilder Pro V6.00.01 or later versions EasyAccess 2.0 (Optional)

Relevant documents

cMT-G02_Datasheet_ENG.pdf
