Siemens PLCs SIMATIC DP, Electronics module ET200S 6ES7131-4BD01-0AB0

Series#: Siemens PLCs

Availability:



Inquire

Product Description

Product Details

Siemens PLCs SIMATIC DP, Electronics module ET200S 6ES7131-4BD01-0AB0
We are First Class Siemens Supplier,siemens plc dealer and Siemens plc distributor in China.
We can Supply Siemens automation parts,such as Siemens PLC,Siemens Servo Motor,Siemens HMI,Siemens VFD and So on,
100% Original and new,In stock by Siemens Automation
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Specification

Article number	6ES7131-4BB01-0AA0	6ES7131-4BB01-0AB0	6ES7131-4BD01-0AA0	6ES7131-4BD01-0AB0	6ES7131-4BF00-0AA0
	ET200S, El-Mod., 2DI ST, DC 24V, 5pcs.	ET200S, El-Mod., 2DI HF, DC 24V, 5pcs.	ET200S, El-Mod., 4DI ST., DC 24V, 5pcs.	ET200S, El-Mod., 4DI HF, DC 24V, 5PC.	ET200S, ELEcTRONIc Module, 8DI DC 24V
Supply voltage
Rated value (DC)
● 24 V DC	Yes; From power module	Yes; From power module	Yes; From power module	Yes; From power module	Yes
Reverse polarity protection	Yes	Yes	Yes	Yes	Yes
Input current
from supply voltage L+, max.	Dependent on encoder	Dependent on encoder	Dependent on encoder	Dependent on encoder	Dependent on encoder
from backplane bus 3.3 V DC, max.	10 mA	10 mA	10 mA	10 mA	10 mA
Encoder supply
Number of outputs					0; no encoder supply
Type of output voltage	min. L+ (-0.5 V), under load	min. L+ (-0.5 V), under load	min. L+ (-0.5 V), under load	min. L+ (-0.5 V), under load
Short-circuit protection		Yes; Electronic		Yes; Electronic
Output current
● Rated value	500 mA	500 mA	500 mA	500 mA
● permissible range, lower limit	0 mA	0 mA	0 mA	0 mA
● permissible range, upper limit	500 mA	500 mA	500 mA	500 mA
Power loss
Power loss, typ.	0.4 W	0.4 W	0.7 W	0.7 W	1.2 W
Address area
Address space per module
● Address space per module, max.	1 byte	1 byte	1 byte	1 byte	1 byte
● with packing	2 bit	2 bit	4 bit	4 bit
Digital inputs
Number of digital inputs	2	2	4	4	8
Input characteristic curve in accordance with IEC 61131, type 1	Yes	Yes	Yes	Yes	Yes; 2-wire sensors connectable
Input voltage
● Type of input voltage	DC	DC	DC	DC	DC
● Rated value (DC)	24 V	24 V	24 V	24 V	24 V
● for signal “0”	-30 to +5 V	-30 to +5 V	-30 to +5 V	-30 to +5 V	-30 to +5 V
● for signal “1”	+15 to +30 V	+11 to +30V	+15 to +30 V	+11 to +30V	+15 to +30 V
Input current
● for signal “1”, typ.	7 mA; at 24 V	8 mA	7 mA; at 24 V	8 mA	5 mA
Input delay (for rated value of input voltage)
for standard inputs
— parameterizable	No	Yes; 0.1 / 0.5 / 3 / 15 ms	No	Yes; 0.1 / 0.5 / 3 / 15 ms	No
— at “0” to “1”, min.	2 ms; typically 3 ms	0.05 / 0.4 / 2.7 / 14.85	2 ms; typically 3 ms	0.05 / 0.4 / 2.7 / 14.85	2 ms
— at “0” to “1”, max.	4.5 ms	0,15 / 0,6 / 3,3 / 15,15	4.5 ms	0,15 / 0,6 / 3,3 / 15,15	4.5 ms
— at “1” to “0”, min.	2 ms; typically 3 ms	0.05 / 0.4 / 2.7 / 14.85	2 ms; typically 3 ms	0.05 / 0.4 / 2.7 / 14.85	2 ms
— at “1” to “0”, max.	4.5 ms	0,15 / 0,6 / 3,3 / 15,15	4.5 ms	0,15 / 0,6 / 3,3 / 15,15	4.5 ms
Cable length
● shielded, max.	1 000 m	1 000 m	1 000 m	1 000 m	1 000 m
● unshielded, max.	600 m	600 m	600 m	600 m	600 m
