Article number | 6ES7134-4FB01-0AB0 | 6ES7134-4LB02-0AB0 | 6ES7134-4GB01-0AB0 | 6ES7134-4GB52-0AB0 |
| ET200S, El-Mod., 2AI Std U, +/-10V,1-5V | ET200S, El-Mod., 2AI U HF, +/-10V, 1..5V | ET200S, El-Mod., 2AI Std I-2DMU, 0-20mA, | ET200S, El-Mod., 2AI HS I-2DMU, 0-20mA, |
Supply voltage |
|
|
|
|
Load voltage L+ |
|
|
|
|
● Rated value (DC)
| 24 V; From power module | 24 V | 24 V; From power module | 24 V |
● Short-circuit protection
|
|
|
| Yes |
● Reverse polarity protection
| Yes | Yes | Yes; Destruction limit 35 mA per channel | Yes |
Input current |
|
|
|
|
from load voltage L+ (without load), max. | 30 mA | 55 mA | 80 mA | 225 mA |
from backplane bus 3.3 V DC, max. | 10 mA | 10 mA | 10 mA | 10 mA |
Output voltage |
|
|
|
|
Power supply to the transmitters |
|
|
|
|
● present
|
| No |
| Yes |
Power loss |
|
|
|
|
Power loss, typ. | 0.6 W | 0.85 W | 0.6 W | 2.5 W |
Address area |
|
|
|
|
Address space per module |
|
|
|
|
● Address space per module, max.
| 4 byte | 4 byte | 4 byte | 4 byte |
Analog inputs |
|
|
|
|
Number of analog inputs | 2 | 2 | 2 | 2 |
permissible input voltage for voltage input (destruction limit), max. | 35 V; 35 V continuous; 75 V for max. 1 ms (mark to space ratio 1:20) | 35 V; 35 V continuous; 75 V for max. 1 ms |
|
|
permissible input current for current input (destruction limit), max. |
|
| 40 mA |
|
Cycle time (all channels) max. | Number of active channels per module x basic conversion time | 0.5 ms; 0.5 ms for 2 channels without noise suppression, 18 / 21 ms per channel with noise suppression | Number of active channels per module x basic conversion time | 0.25 ms |
Input ranges (rated values), voltages |
|
|
|
|
● 1 V to 5 V
| Yes | Yes |
|
|
— Input resistance (1 V to 5 V)
|
| 800 kΩ |
|
|
● -10 V to +10 V
| Yes | Yes |
|
|
— Input resistance (-10 V to +10 V)
|
| 800 kΩ |
|
|
● -5 V to +5 V
| Yes | Yes |
|
|
— Input resistance (-5 V to +5 V)
|
| 800 kΩ |
|
|
Input ranges (rated values), currents |
|
|
|
|
● 0 to 20 mA
|
|
|
| Yes |
— Input resistance (0 to 20 mA)
|
|
|
| 106 Ω |
● 4 mA to 20 mA
|
|
| Yes; on 50 ohms | Yes |
Cable length |
|
|
|
|
● shielded, max.
| 200 m | 200 m | 200 m | 200 m |
Analog value generation for the inputs |
|
|
|
|
Integration and conversion time/resolution per channel |
|
|
|
|
● Resolution with overrange (bit including sign), max.
| 14 bit; ±10 V: 13 bit + sign, ±5 V: 13 bit + sign; 1 to 5 V: 13 bit | 16 bit; 0 to 5 V: 15 bit, ±10 V: 16 bit, ±5 V: 16 bit | 13 bit; 4 to 20 mA: 13 bit | 16 bit |
● Integration time, parameterizable
| Yes | Yes |
|
|
● Integration time (ms)
| 16,7 / 20 ms |
| 16,7 / 20 ms |
|
● Interference voltage suppression for interference frequency f1 in Hz
| 50 / 60 Hz | 60 / 50 Hz / no | 50 / 60 Hz |
|
● Conversion time (per channel)
| 65 ms; 55 / 65 ms | 0.04 ms; Without noise suppression 17/20 ms per channel with error | 65 ms; 55 / 65 ms |
|
Encoder |
|
|
|
|
Connection of signal encoders |
|
|
|
|
● for voltage measurement
|
| Yes |
|
|
● for current measurement as 2-wire transducer
|
|
|
| Yes |
Errors/accuracies |
|
|
|
|
Operational error limit in overall temperature range |
|
|
|
|
● Voltage, relative to input range, (+/-)
| 0.6 % | 0.1 %; 0.2% without interference frequency suppression |
|
|
● Current, relative to input range, (+/-)
|
|
| 0.6 % | 0.3 % |
Basic error limit (operational limit at 25 °C) |
|
|
|
|
● Voltage, relative to input range, (+/-)
| 0.4 % | 0.05 %; 0.1% without interference frequency suppression |
|
|
● Current, relative to input range, (+/-)
|
|
| 0.4 % | 0.2 % |
Interrupts/diagnostics/status information |
|
|
|
|
Alarms |
|
|
|
|
● Hardware interrupt
|
| Yes |
| Yes |
Diagnoses |
|
|
|
|
● Wire-break
| Yes; Measuring range 1 to 5 V only | Yes; Measuring range 1 to 5 V only | Yes | Yes; at 4 to 20 mA |
● Group error
| Yes | Yes | Yes | Yes |
● Overflow/underflow
| Yes | Yes | Yes | Yes |
Diagnostics indication LED |
|
|
|
|
● Group error SF (red)
| Yes | Yes | Yes | Yes |
Parameter |
|
|
|
|
Remark | 4 byte | 12 bytes, 4 bytes in compatibility mode | 4 byte |
|
Diagnostics wire break | Disable / enable (only in measuring range 1 to 5 V) |
|
| At 4 to 20 mA |
Measurement type/range | deactivated / ±5 V / 1 to 5 V / ±10 V | deactivated / ±5 V / 1 to 5 V / ±10 V | deactivated / 4 to 20 mA | 4 to 20 mA, 0 to 20 mA |
Group diagnostics | Disable / enable | Disable / enable | Disable / enable | 1 |
Overflow/underflow | Disable / enable | Disable / enable | Disable / enable | 1 |
Potential separation |
|
|
|
|
Potential separation analog inputs |
|
|
|
|
● between the channels
| No | No; however, increased permissible potential difference between the inputs. | No | No |
● between the channels and backplane bus
| Yes | Yes | Yes | Yes |
● Between the channels and load voltage L+
| Yes | Yes | No | Yes |
Isolation |
|
|
|
|
Isolation tested with | 500 V DC | 500 V DC | 500 V DC |
|
Dimensions |
|
|
|
|
Width | 15 mm | 15 mm | 15 mm | 15 mm |
Height | 81 mm | 81 mm | 81 mm | 81 mm |
Depth | 52 mm | 52 mm | 52 mm | 52 mm |
Weights |
|
|
|
|
Weight, approx. | 40 g | 45 g | 40 g |
|
