| Model | GT-H10 | GT-H22 | GT-H10L | GT-H22L |
| Type | Sensor head: Standard | Sensor head: Low-stress |
| Measuring range | 10 mm 0.39″ | 22 mm 0.87″ | 10 mm 0.39″ | 22 mm 0.87″ |
| Downward mounting | 1.0 N*1 | 1.5 N*1 | 0.3 N*1 | 0.35N*1 |
| Side mounting | 0.9 N*1 | 1.4 N*1 | 0.25N*1 | 0.3 N*1 |
| Upward mounting | 0.8 N*1 | 1.3 N*1 | 0.2 N*1 | 0.25N*1 |
| Mechanical response | 10 Hz (at ambient temperature of 23 °C 73 °F) | 8 Hz (at ambient temperature of 23 °C 73 °F) | 7 Hz (at ambient temperature of 23 °C 73 °F) | 5 Hz (at ambient temperature of 23 °C 73 °F) |
| Repeatability | 3 µm 0.00012″ (at ambient temperature of 23 °C 73 °F)*2 | 8 µm 0.00031″ (at ambient temperature of 23 °C 73 °F)*2 | 3 µm 0.00012″ (at ambient temperature of 23 °C 73 °F)*2 | 8 µm 0.00031″ (at ambient temperature of 23 °C 73 °F)*2 |
|
Enclosure rating | IP67 | – |
| Ambient temperature | -10 to +55 °C 14 to 131 °F |
| Relative humidity | 35 to 85 % RH |
| Material | Housing: TYPE430 Stainless steel, Indicator: Polyarylate,
Dust boot: NBR, Contact: TYPE304 stainless steel, Cable: PVC | Housing: TYPE430 Stainless steel, Indicator: Polyarylate,
Contact: TYPE304 stainless steel, Cable: PVC |
| Weight | Approx. 115 g (With 2-m 6.6′ cable) | Approx. 135 g (With 2-m 6.6′ cable) | Approx. 115 g (With 2-m 6.6′ cable) | Approx. 135 g (With 2-m 6.6′ cable) |
