Mitsubishi CP30-BA2P1MD7A CP30-BA Series Circuit Protector 2-Pole 7A DC

Series#: Circuit Breaker -> Mitsubishi Circuit Breakers
- Mitsubishi CP30-BA2P1MD7A CP30-BA Series Circuit Protector 2-Pole 7A DC
- We have large inventory for Mitsubishi CP30-BA Series Circuit Protectors, Mitsubishi DC circuit protectors and related accessories.
- 100% Original and new,In stock by Eaton Company.
- Delivery time: Ready in stock and 1 days for ship out
- MOQ: 1pcs

Availability:



Inquire

Model:
CP30-BA2P1MD7A
Brand:
Mitsubishi Electric

Product Description

The Mitsubishi CP30-BA2P1MD7A is a 2-pole 7A DC-optimized circuit protector from the CP30-BA series. The MD suffix designates a trip characteristic optimized for DC circuits (DC Medium trip), making it suitable for protecting DC control circuits up to 125VDC (2-pole series connection). Applications include DC motor control circuit protection, DC solenoid and actuator circuits, battery-powered industrial equipment, solar panel combiner box protection, and 24VDC/48VDC industrial power distribution protection.

Technical Specifications

Mitsubishi Electric CP30-BA2P1MD7A
Circuit Breaker -> Mitsubishi Circuit Breakers \| The Mitsubishi CP30-BA2P1MD7A is a 2-pole 7A DC-optimized circuit protector from the CP30-BA series. The MD suffix designates a trip characteristic optimized for DC circuits (DC Medium trip), making i
Feature	Specification
Feature	Specification
Series	CP30-BA
Model	CP30-BA2P1MD7A
Type	Circuit Protector (Miniature Circuit Breaker, DC Rated)
Number of Poles	2-Pole (2P)
Rated Current	7 A
Rated Voltage (AC)	250 VAC
Rated Voltage (DC)	125 VDC (2P in series)
Trip Characteristic	MD-type (DC Medium trip)
Breaking Capacity (Icu)	2.5 kA (230VAC, IEC60947)
Width	35 mm (2 x 17.5mm)
Mounting	DIN Rail (35mm)
Connection	Screw-clamp terminals
Standards	IEC60947-2, UL1077
