Mitsubishi CP30-BA2P21MD2A CP30-BA Series Circuit Protector 2-Pole 2A DC

Series#: Circuit Breaker -> Mitsubishi Circuit Breakers
- Mitsubishi CP30-BA2P21MD2A CP30-BA Series Circuit Protector 2-Pole 2A DC
- We have large inventory for Mitsubishi CP30-BA Series Circuit Protectors, Mitsubishi DC rated circuit protectors and related accessories.
- 100% Original and new,In stock by Eaton Company.
- Delivery time: Ready in stock and 1 days for ship out
- MOQ: 1pcs

Availability:



Inquire

Model:
CP30-BA2P21MD2A
Brand:
Mitsubishi Electric

Product Description

The Mitsubishi CP30-BA2P21MD2A is a 2-pole 2A DC-optimized circuit protector featuring MD-type (DC Medium) trip characteristic. With 2-pole series connection, it provides reliable protection for DC circuits up to 125VDC. The low 2A rating makes it ideal for sensitive DC electronic circuits. Applications include DC sensor and transducer protection, 24VDC PLC input module protection, DC relay and contactor coil circuits, battery management system auxiliary protection, and industrial DC power supply output protection.

Technical Specifications

Mitsubishi Electric CP30-BA2P21MD2A
Circuit Breaker -> Mitsubishi Circuit Breakers \| The Mitsubishi CP30-BA2P21MD2A is a 2-pole 2A DC-optimized circuit protector featuring MD-type (DC Medium) trip characteristic. With 2-pole series connection, it provides reliable protection for DC ci
Feature	Specification
Feature	Specification
Series	CP30-BA
Model	CP30-BA2P21MD2A
Type	Circuit Protector (Miniature Circuit Breaker, DC Rated)
Number of Poles	2-Pole (2P)
Rated Current	2 A
Rated Voltage (AC)	250 VAC
Rated Voltage (DC)	125 VDC (2P in series)
Trip Characteristic	MD-type (DC Medium trip)
Breaking Capacity (Icu)	2.5 kA (230VAC, IEC60947)
Width	35 mm (2 x 17.5mm)
Mounting	DIN Rail (35mm)
Connection	Screw-clamp terminals
Standards	IEC60947-2, UL1077
