| Display | 12.1” TFT |
| Resolution | 1024 x 768 |
| Brightness (cd/m2) | 500 |
| Contrast Ratio | 700:1 |
| Backlight Type | LED |
| Backlight Life Time | >50,000 hrs. |
| Colors | 16.2M |
| LCD Viewing Angle (T/B/L/R) | 80/80/80/80 |
| Type | 4-wire Resistive Type |
| Accuracy | Active Area Length(X)±2%, Width(Y)±2% |
| Flash | 256 MB |
| RAM | 256 MB |
| Processor | 32 bit RISC CPU 800MHz |
| SD Card Slot | SD/SDHC |
| USB Host | USB 2.0 x 1 |
| USB Client | USB 2.0 x 1 |
| Ethernet | 10/100 Base-T x 1 |
| COM Port | COM1: RS-232/RS-485 2W/4W COM3: RS-232/RS-485 2W* |
| RS-485 Dual Isolation | Yes |
| CAN Bus | Yes |
| HDMI | N/A |
| Audio Output | N/A |
| Video Input | N/A |
| RTC | Built-in |
| Input Power | 24±20%VDC |
| Power Isolation | Built-in |
| Power Consumption | 850m A@24VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW at 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating | Yes |
| Enclosure | Aluminum |
| Dimensions WxHxD | 317 x 244 x 46 mm |
| Panel Cutout | 305 x 231 mm |
| Weight | Approx. 2.1 kg |
| Mount | Panel mount, VESA mount 75 x 75 mm |
| Protection Structure | NEMA 4 / IP66 Compliant Front Panel |
| Storage Temperature | -20° ~ 70°C (-4° ~ 158°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| CE | CE marked |
| UL | cULus Listed |
| Software | EasyBuilder Pro |
