| Display | 7” TFT |
| Resolution | 800 x 480 |
| Brightness (cd/m2) | 500 |
| Contrast Ratio | 500:1 |
| Backlight Type | LED |
| Backlight Life Time | >30,000 hrs. |
| Colors | 16.7M |
| LCD Viewing Angle (T/B/L/R) | 60/50/65/65 |
| Touch Panel Type | 4-wire Resistive Type |
| Touch Panel Accuracy | Active Area Length(X)±2%, Width(Y)±2% |
| Memory Flash | 256 MB |
| Memory RAM | 256 MB |
| Processor | 32 bits RISC Cortex-A8 1GHz |
| Processor SD Card Slot | SD/SDHC |
| Processor USB Host | USB 2.0 x 1 |
| Processor USB Client | USB 2.0 x 1 (Micro USB) |
| Processor Ethernet | 10/100 Base-T x 1 |
| I/O Port COM Port | COM1: RS-232/RS-485 2W/4W, COM3: RS-232/RS-485 2W* |
| I/O Port RS-485 Dual Isolation | Yes |
| I/O Port CAN Bus | Yes |
| I/O Port HDMI | N/A |
| I/O Port Audio Output | N/A |
| I/O Port Video Input | N/A |
| RTC | Built-in |
| Input Power | 24±20%VDC |
| Power Isolation | Built-in |
| Power Consumption | 400m A@24VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW at 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating | Yes |
| Enclosure | Aluminum |
| Dimensions WxHxD | 200.3 x 146.3 x 42.5 mm |
| Panel Cutout | 192 x 138 mm |
| Weight | Approx. 0.9 kg |
| Mount | Panel mount |
| Protection Structure | UL Type 4X (indoor use only) / NEMA4 / IP66 Compliant Front Panel |
| Storage Temperature | -20° ~ 70°C (-4° ~ 158°F) |
| Operating Temperature | -20° ~ 50°C (-4° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| CE | CE marked |
| UL | cULus Listed |
| Software | EasyBuilder Pro V5.00.01 or later versions |
