| Item Model | TL-Q2MC1 | TL-Q5MC@/TL-Q5MB1 |
| Sensing distance | 2 mm ±15% | 5 mm ±10% |
| Set distance | 0 to 1.5 mm | 0 to 4 mm |
| Differential travel | 10% max. of sensing distance |
|
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on page 6.) |
|
| Standard sensing object | Iron, 8 ´ 8 ´ 1 mm | Iron, 15 ´ 15 ´ 1 mm |
| Response time | — | 2 ms max. |
| Response frequency * | 500 Hz |
|
| Power supply volt- age (operating volt- age range) |
12 to 24 VDC (10 to 30 VDC), ripple (p-p): 10% max. |
|
| Current consumption | 15 mA max. at 24 VDC (no-load) | 10 mA max. at 24 VDC |
| Load current |
NPN open collector 100 mA max. at 30 VDC max. | TL-Q5MC@: NPN open collector,
50 mA max. at 30 VDC max. TL-Q5MB@: PNP open collector, 50 mA max. at 30 VDC max. |
| Residual voltage | 1 V max. (under load current of 100 mA with cable length of 2 m) | 1 V max. (under load current of 50 mA with cable length of 2 m) |
| Indicators | Detection indicator (red) |
|
| Operation mode (with sensing object approaching) | NO | B1/C1 Models: NO C2 Models: NC |
| Protection circuits | Reverse polarity protection, Surge suppressor |
|
| Ambient temperature range | Operating/Storage: -10 to 60°C (with no icing or condensa- tion) | Operating/Storage: -25 to 70°C (with no icing or condensa- tion) |
| Ambient humidity range | Operating/Storage: 35% to 95% (with no condensation) |
|
| Temperature influence | ±10% max. of sensing distance at 23°C in the temperature range of -10 to 60°C | ±20% max. of sensing distance at 23°C in the temperature range of -25 to 70°C |
| Voltage influence | ±2.5% max. of sensing distance at rated voltage in rated voltage ±10% range |
|
| Insulation resistance | 50 MΩ min. (at 500 VDC) between current-carrying parts and case | 5 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Dielectric strength | 1,000 VAC for 1 min between current-carrying parts and case | 500 VAC, 50/60 Hz for 1 min between current-carrying parts and case |
| Vibration resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
|
| Shock resistance | Destruction: 1,000 m/s2 10 times each in X, Y, and Z direc- tions | Destruction: 200 m/s2 10 times each in X, Y, and Z direc- tions |
| Degree of protection | IEC 60529 IP67,
in-house standards: oil-resistant | IEC IP67 |
| Connection method | Pre-wired Models (Standard cable length: 2 m) |
|
| Weight (packed state) | Approx. 60 g | Approx. 90 g |
